| 1. |
607890R1
|
[3] |
WASHER
|
IH
1-7/32 x 1-3/4 x 16 ga C-Z, (or as required)
|
| 2. |
553050R1
|
[1] |
LOCK PIN,1/4" x 1 3/4", Slotted
|
IH
Pin, 1/4" x 1 3/4", Slotted Superseded by part number: 87343
|
| 3. |
30490R1
|
[1] |
KEY,M 8 x 7 x 32
|
IH
8 x 7 x 32 parallel
|
| 4. |
3102818R1
|
[2] |
GEAR
|
IH
CAM, gear
|
| 5. |
30469R1
|
[1] |
KEY,M 8 x 7 x 50
|
IH
8 x 7 x 50 parallel
|
| 6. |
607894R1
|
[1] |
WASHER
|
IH
1-7/32 x 1-3/4 x 22 ga C-Z
|
| 7. |
667588R1
|
[1] |
DISC
|
IH
SHIM, knotter to cam .007
|
| 7. |
316171C1
|
[1] |
SHIM
|
IH
knotter to cam .005
|
| 8. |
3102817R91
|
[2] |
KNOTTER
|
IH
ASSY, see detail list for service
|
| . . |
180124
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
|
IH
3/8 x 1-1/4 type 5 Superseded by part number: 88011
|
| . . |
180126
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/2", Gr 5
|
IH
3/8 x 1-1/2 type 5 Superseded by part number: 113-209
|
| . . |
3063560R1
|
[2] |
LOCK NUT
|
IH
3/8 lock
|
| . . |
120394
|
[3] |
WASHER,3/8", SAE
|
IH
WASHER, .406 x .812 x .051, (or as required) Superseded by part number: 87016
|
| . . |
321204
|
[5] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
NIPPLE, LUBE, M6 x 1, 16mm lg
|
| . . |
905251R1
|
[2] |
LUBE NIPPLE,90 Degree, M6 x 1
|
IH
FITTING, 90 deg lub, M6
|
| 9. |
3102926R1
|
[2] |
COLLAR
|
IH
knotter shaft adjusting
|
| . . |
3102927R1
|
[4] |
CLEVIS PIN
|
IH
STUD, 1/8 x 1/2 grooved
|
| . . |
3100005R1
|
[1] |
ELECTRICAL WIRE
|
IH
WIRE, 16 ga x 28 inch
|
| 10. |
3102917R1
|
[1] |
CAM
|
IH
tucker finger
|
| 11. |
30489R1
|
[1] |
KEY,M 8 x 7 x 20
|
IH
5 x 7 x 20 parallel
|
| 16. |
3103087R91
|
[1] |
BEARING ASSY
|
IH
ASSY LH KNOTTER SHAFT, consists of
|
| . . |
3102908R1
|
[1] |
BALL BEARING
|
IH
|
| . . |
3102891R1
|
[2] |
FLANGE
|
IH
or
|
| 16. |
3103649R91
|
[1] |
NO LONGER SERVICED
|
IH
BEARING ASSY, LH knotter shaft Superseded by part number: 3103087R91
|
| . . |
495967R1
|
[2] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 1", G5, Full Thd
|
IH
BOLT, 3/8 x 1 crg type 5 Superseded by part number: 80280503
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 17. |
3102913R1
|
[1] |
SHAFT
|
IH
knotter
|
| 18. |
3102900R1
|
[1] |
THRUST WASHER
|
IH
thrust
|
