现代零件查询R210LC-7A PILOT HYD PIP(BASE2, #0794-, MCV TYPE 2)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
509 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 3. |
31MH-20310
|
[1] |
FILTER-LINE
|
|
| 3-1. |
31MH-20320
|
[1] |
ELEMENT-LINE FILTER
|
|
| 6. |
31Q6-20210
|
[1] |
CONNECTOR-ORFS
|
|
| 7. |
31Q6-20220
|
[1] |
HOSE ASSY-ORFS
|
|
| 7. |
31Q6-20430
|
[1] |
HOSE ASSY-ORFS
|
|
| 8. |
P920-122009
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 9. |
P930-122012
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 15. |
P930-082012
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 17. |
X400-042010
|
[1] |
HOSE ASSY-SYNF,ORFS
|
|
| 21. |
X410-042008
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 25. |
X420-042008
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 26. |
X420-042010
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 29. |
X420-042009
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 30. |
X400-042008
|
[2] |
HOSE ASSY-SYNF,ORFS
|
|
| 33. |
X400-042041
|
[1] |
HOSE ASSY-SYNF,ORFS
|
|
| 35. |
31EK-11130
|
[4] |
COUPLING-SCREW
|
|
| 37. |
31N6-22400
|
[1] |
ADAPTOR
|
|
| 42. |
X500-110001
|
[4] |
CONNECTOR-ORFS
|
|
| 44. |
X500-110003
|
[1] |
CONNECTOR-ORFS
|
|
| 45. |
X500-110004
|
[2] |
CONNECTOR-ORFS
|
|
| 47. |
X500-110013
|
[1] |
CONNECTOR-ORFS
|
|
| 50. |
X520-110001
|
[4] |
ELBOW-90,ORFS
|
|
| 52. |
X520-110003
|
[2] |
ELBOW-90,ORFS
|
|
| 53. |
X520-110004
|
[1] |
ELBOW-90,ORFS
|
|
| 54. |
X520-110012
|
[1] |
ELBOW-90,ORFS
|
|
| 57. |
X820-045151
|
[1] |
ADAPTER-TEE
|
|
| 62. |
S621-011001
|
[4] |
O-RING
|
|
| 65. |
S621-018001
|
[1] |
O-RING
|
|
| A. |
S621-011001
|
[14] |
O-RING
|
|
| C. |
S621-014001
|
[2] |
O-RING
|
|
| D. |
S621-018001
|
[5] |
O-RING
|
|
| F. |
S631-008004
|
[1] |
O-RING
|
|
| G. |
S631-011004
|
[13] |
O-RING
|
|
| H. |
S631-014004
|
[2] |
O-RING
|
|
| I. |
S631-018004
|
[3] |
O-RING
|
|
| J. |
S631-024004
|
[4] |
O-RING
|
|
