现代零件查询R210LC-7A PILOT HYD PIP(BASE3, #0794-, MCV TYPE 2)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
895 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
31E5-40500
|
[1] |
SWITCH-PRESSURE
|
|
| 6. |
31Q6-20210
|
[1] |
CONNECTOR-ORFS
|
|
| 18. |
P930-043045
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 20. |
P930-062014
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 23. |
P930-043054
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 26. |
X420-042010
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 27. |
X420-042012
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 28. |
X420-042007
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 31. |
X420-042040
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 32. |
X420-042041
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 39. |
31N4-22150
|
[1] |
TEE-LONG,ORFS
|
|
| 40. |
X820-065152
|
[1] |
TEE-R/TYPE,ORFS
|
|
| 41. |
31N8-40100
|
[2] |
CONNECTOR-LONG,ORFS
|
|
| 42. |
X500-110001
|
[4] |
CONNECTOR-ORFS
|
|
| 43. |
31E5-11110
|
[1] |
ADAPTER
|
|
| 47. |
X500-110013
|
[2] |
CONNECTOR-ORFS
|
|
| 50. |
X520-110001
|
[2] |
ELBOW-90,ORFS
|
|
| 60. |
X840-515151
|
[1] |
TEE-R/TYPE,SWIVEL,ORFS
|
|
| 61. |
S035-082526
|
[2] |
BOLT-W/WASHER
|
|
| 62. |
S621-011001
|
[2] |
O-RING
|
|
| 63. |
S621-012001
|
[1] |
O-RING
|
|
| A. |
S621-011001
|
[14] |
O-RING
|
|
| B. |
S621-012001
|
[1] |
O-RING
|
|
| F. |
S631-008004
|
[1] |
O-RING
|
|
| G. |
S631-011004
|
[12] |
O-RING
|
|
| H. |
S631-014004
|
[1] |
O-RING
|
|
