纽荷兰零件查询(FD20) - CRAWLER DOZER (D1.01[001]) - FRAME New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
569 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4957707. | 4957707 | [16] | SCREW | LEC |
| 4966394. | 4966394 | [1] | TOW HOOK | JESHOOK |
| 10517271. | 10517271 | [4] | LOCK WASHER,16.2mm ID x 27.7mm OD x 4mm Thk | BHBLOCKWASHER Superseded by part number: 10572173 |
| 11195071. | 11195071 | [16] | WASHER | LECLOCKWASHER |
| 12164127. | 12164127 | [4] | NUT,M16 x 1.5, Cl 10 | LEC Superseded by part number: 12164124 |
| 15981037. | 15981037 | [4] | SCREW | LEC Superseded by part number: 15981034 |
| 76005206. | 76005206 | [1] | FRAME | NH |
| 79005257. | 79005257 | [1] | FRAME | LEC |
| 79033231. | 79033231 | [1] | FRAME | LEC |
