纽荷兰零件查询(FD20) - CRAWLER DOZER (C1.35[001]) - BRAKE HAND CONTROL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
673 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4984562. | 4984562 | [1] | GUIDE | LECSLIDE GUIDE Superseded by part number: 76004839 |
| 4985147. | 4985147 | [1] | HANDLE GRIP | LECKNOB |
| 4985332. | 4985332 | [1] | TORSION SPRING | LEC |
| 10005010. | 10005010 | [1] | PIN | MKT Superseded by part number: 10005011 |
| 10248471. | 10248471 | [1] | YOKE | MKTFORK |
| 10520001. | 10520001 | [3] | WASHER,12.2mm ID x 22mm OD x 3mm Thk | BHB Superseded by part number: 17095304 |
| 10520101. | 10520101 | [2] | WASHER,14.4mm ID x 26mm OD x 3mm Thk | TTF Superseded by part number: 17095504 |
| 10733601. | 10733601 | [2] | COTTER PIN,M3.2 x 22 | TTFPIN, SPLIT (COTTER), M3.2 x 22 |
| 10791221. | 10791221 | [1] | NUT | MKT Superseded by part number: 399555 |
| 10796401. | 10796401 | [3] | COTTER PIN,M3.2 x 18 | TTFSPLIT PIN Superseded by part number: |
| 13401175. | 13401175 | [1] | LOCKING RING | MKTLOCKRING Superseded by part number: 13401176 |
| 14549170. | 14549170 | [2] | BUSHING | LECBUSH |
| 14603770. | 14603770 | [2] | LOCK PIN,M6 x 22, Slotted | MKTPIN |
| 76004839. | 76004839 | [1] | GUIDE | LECSLIDE GUIDE |
| 79005586. | 79005586 | [1] | PIN | LEC |
| 79005959. | 79005959 | [2] | SPRING | LEC |
| 79005962. | 79005962 | [2] | RATCHET | LEC |
| 79007115. | 79007115 | [1] | SHAFT | LEC |
| 79007120. | 79007120 | [2] | SHAFT | LEC |
| 79007121. | 79007121 | [1] | LEVER | LEC |
| 79010263. | 79010263 | [2] | PIN | LEC |
| 79012903. | 79012903 | [1] | STRUT | LEC |
| 79012907. | 79012907 | [1] | LEVER | LEC Superseded by part number: 79026658 |
