纽荷兰零件查询(FD20) - CRAWLER DOZER (D1.02/2[001]) - REAR TOW HOOK New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
506 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 567406. | 5112606 | [2] | COTTER PIN | TTFSPLIT PIN |
| 4955502. | 4955502 | [1] | CHAIN | BHB |
| 4957707. | 4957707 | [8] | SCREW | LEC |
| 4961487. | 4961487 | [1] | BUSHING | LECBUSH |
| 4961837. | 4961837 | [1] | SWINGING DRAWBAR | LECCROSSRAIL |
| 4961849. | 4961849 | [2] | PLATE | LEC |
| 4961852. | 4961852 | [1] | PIN | LEC |
| 4961853. | 4961853 | [2] | PIN | LEC |
| 8268534. | 8268534 | [1] | ROLL PIN,7mm OD | LECPIN |
| 10572571. | 10572571 | [6] | LOCK WASHER | MKTLOCKWASHER Superseded by part number: 86509829 |
| 11195071. | 11195071 | [8] | WASHER | LECLOCKWASHER |
| 12164527. | 12164527 | [6] | NUT,M24 x 1.5, Cl 10 | LEC |
| 13921070. | 13921070 | [1] | ROLL PIN,M12 x 95, Coiled | LECPIN |
| 15997131. | 15997131 | [5] | BOLT,Hex, M24 x 2 x 60mm, Cl 10.9 | MKT Superseded by part number: 15997137 |
| 15997931. | 15997931 | [6] | BOLT,Hex, M24 x 2 x 120mm, Cl 10.9 | LECSCREW |
| 79029455. | 79029455 | [1] | DRAWBAR | LEC |
| 79029456. | 79029456 | [1] | PIN | LEC |
| 79029457. | 79029457 | [1] | SUPPORT | LECREINFORCEMENT |
| 79029458. | 79029458 | [1] | CONSOLE | LECREINFORCEMENT |
| 79029459. | 79029459 | [1] | SUPPORT | LEC |
