纽荷兰零件查询(FD20) - CRAWLER DOZER (D2.20[001]) - STEERING CLUTCHES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
799 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 586751. | 586751 | [2] | SCREW | LEC |
| 590389. | 590389 | [2] | COVER PLATE | LECPLAQUE |
| 590390. | 590390 | [2] | SNAP RING | LECLOCKRING |
| 4958055. | 4958055 | [2] | HUB | LEC Superseded by part number: 9593778 |
| 4958057. | 4958057 | [2] | PISTON | LEC Superseded by part number: 76007901, 76007902 |
| 4958059. | 4958059 | [2] | GUIDE | LEC |
| 4958063. | 4958063 | [2] | RING | LEC |
| 4989677. | 4989677 | [6] | RING | LECLOCKRING Superseded by part number: 79061079 |
| 10336210. | 10336210 | [2] | DOWEL,M6 x 20 | MKT |
| 10839510. | 10839510 | [2] | DOWEL,M6 x 9 | TTF Superseded by part number: 17275310 |
| 14257830. | 14257830 | [20] | BOLT,Hex, M16 x 1.5 x 35mm, Cl 10.9 | BHB Superseded by part number: 14257834 |
| 14466681. | 14466681 | [2] | O-RING,120.24mm ID x 5.012" OD x 3.53mm | LEC-248, Cl 7, 4.734" ID x .139" Thk (M120.24 ID x 3.53 Thk) Superseded by part number: 4897111 |
| 14468281. | 14468281 | [2] | O-RING,190.1mm ID x 7.762" OD x 3.53mm | LEC-264, Cl 7, 7.484" ID x .139" Thk (M190.1 ID x 3.53 Thk) |
| 76007901. | 76007901 | [2] | PISTON | LEC |
| 76007902. | 76007902 | [2] | RING,195.7mm ID x 202.05mm OD x 6mm Thk | LEC |
| 79061079. | 79061079 | [6] | SEALING RING,120.2mm ID x 132.04mm OD x 4mm Thk | LECLOCKRING |
