纽荷兰零件查询(FD20) - CRAWLER DOZER (D2.20[002]) - STEERING CLUTCHES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
489 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 586746. | 586746 | [16] | | LEC Superseded by part number: LEC586746, LEC586746, NLS |
| 586747. | 586747 | [16] | SPRING | LEC |
| 586748. | 586748 | [16] | WASHER | LEC |
| 589025. | 589025 | [1] | CLUTCH DRIVING PLATE | LEC |
| 4958054. | 4958054 | [2] | DRUM | LEC |
| 4958061. | 4958061 | [2] | RING | LECPRESSURE PLATE |
| 4958062. | 4958062 | [16] | PROP | LECSTUD BOLT |
| 4958065. | 4958065 | [16] | SPACER | LEC |
| 4958066. | 4958066 | [8] | LOCKING PLATE | LECLOCKPLATE |
| 4958069. | 4958069 | [30] | DISC | MKTCLUTCH DRIVEN PLATE |
| 4959448. | 4959448 | [30] | PLATE | MKTCLUTCH DRIVEN PLATE Superseded by part number: 4958069 |
| 4967222. | 4967222 | [2] | HUB | LEC Superseded by part number: 93200547 |
| 4979644. | 4979644 | [1] | CLUTCH DRIVING PLATE | LEC Superseded by part number: 589025 |
| 14274530. | 16326234 | [32] | BOLT,Hex, M12 x 1.25 x 30mm, Cl 10.9 | JESSCREW |
| 76007900. | 76007900 | [2] | DRUM | LEC |
| 79006765. | 79006765 | [16] | SPRING | LEC |
| 79006766. | 79006766 | [16] | SPRING | LEC |
| 79066329. | 79066329 | [22] | CLUTCH PLATE | LECCLUTCH DRIVEN PLATE |
| 79066441. | 79066441 | [2] | RING | LECPRESSURE PLATE |
