| 1. |
3103037R91
|
[1] |
CONTAINER
|
IH
CHEST ASSY, twine
|
| . . |
16897R1
|
[5] |
CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 5/16 x 3/4 crg type 1 Superseded by part number: 412-512
|
| . . |
9635082
|
[5] |
NUT,5/16" - 18, Gr 5
|
NH
5/16 pln hex
|
| . . |
103320
|
[5] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| . . |
440-12510
|
[2] |
SCREW,Cross Pan Hd, 1/4"-20 x 5/8"
|
CAS
1/4-20 x 5/8 slt truss hd Superseded by part number: 86511931
|
| . . |
109084
|
[2] |
NUT,1/4"-20, G5
|
IH
Superseded by part number: 7770
|
| . . |
103319
|
[2] |
LOCK WASHER,1/4"
|
IH
WASHER, LOCK, 1/4" Superseded by part number: 92-11025
|
| 2. |
674186R1
|
[4] |
HOOK
|
IH
twine can door S
|
| 3. |
674185R1
|
[2] |
CHAIN (AG)
|
IH
CHAIN, twine can door
|
| . . |
85700996
|
[2] |
SCREW,Phillips Drive, Pan HD, 1/4" - 20 x 1/2"
|
WIN
1/4-20 x 1/2 slt-truss-hd
|
| . . |
21549R1
|
[2] |
WASHER
|
IH
.281 x .750 x .042 Superseded by part number: 495-81106
|
| 4. |
269920R2
|
[2] |
SPRING
|
IH
twine door clamp
|
| 5. |
3103045R1
|
[2] |
CLAMP ASSY, twine can door
|
|
| . . |
137185
|
[2] |
COTTER PIN,1/8" x 1"
|
IH
PIN, SPLIT (COTTER), 1/8" x 1" Superseded by part number: 80755
|
| . . |
20803R1
|
[2] |
WASHER
|
IH
.406 x 1.000 x .105 Superseded by part number: 87613212
|
| 7. |
3103046R1
|
[2] |
FERRULE
|
IH
twine door clamp
|
| 8. |
662372R1
|
[1] |
GROMMET
|
IH
Superseded by part number: 662371R91
|
| 10. |
655108R2
|
[2] |
GUIDE
|
IH
twine
|
| . . |
106883
|
[4] |
RIVET,Truss Hd, 3/16" x 3/8"
|
IH
Superseded by part number: 87467
|
| 11. |
662380R1
|
[2] |
GUIDE
|
IH
PLATE, twine tension
|
| 13. |
B32120
|
[2] |
WASHER
|
IH
twine roller spring cup
|
| . . |
495058R2
|
[2] |
BOLT,Carriage, 1/4" - 20 x 3"
|
IH
1/4 x 3 sq-nk crg
|
| . . |
86627130
|
[2] |
WING NUT,1/4"-20
|
NH
NUT, 1/4 wing
|
| 14. |
3101464R1
|
[1] |
SUPPORT
|
IH
assy twine can
|
| . . |
18508R1
|
[2] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 crg type 1 Superseded by part number: 86508748
|
| . . |
17351R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 crg type 1 Superseded by part number: 88682
|
| . . |
102635
|
[4] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[4] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 15. |
3102155R1
|
[1] |
HOLDER
|
IH
shear bolt
|
| 16. |
3102165R1
|
[2] |
GUIDE
|
IH
twine Superseded by part number: 3102165R2
|
| 17. |
352133R1
|
[2] |
PLATE
|
IH
guide mounting
|
| . . |
436730
|
[4] |
LOCK SCREW,Slotted Pan Hd, #10-24 x 3/8"
|
IH
SCREW, no. 10 x 3/8 znp p/hds mach Superseded by part number: 159908
|
| . . |
120361
|
[4] |
NUT,Hex Mach Screw, #10 - 24
|
IH
Superseded by part number: 87304
|
| . . |
120217
|
[4] |
LOCK WASHER,#10
|
IH
WASHER, LOCK, #10 Superseded by part number: 80684
|
