| 1. |
20703R1
|
[1] |
WASHER
|
IH
.906 x 1.750 x .054 Superseded by part number: 495-81059
|
| 2. |
103449
|
[2] |
PIN, 1/4 x 1-1/4 slotted spring
|
|
| 3. |
3102977R1
|
[1] |
SHAFT
|
IH
ASSY
|
| 4. |
3102805R1
|
[2] |
BRACKET
|
IH
meter wheel shaft bearing
|
| . . |
18508R1
|
[4] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 crg type 1 Superseded by part number: 86508748
|
| . . |
102635
|
[4] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[4] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
619586R1
|
[4] |
WASHER, 13/32 x 1 x 16 ga
|
|
| 5. |
668999R1
|
[2] |
BUSHING
|
IH
meter wheel, or
|
| 5. |
3101216R1
|
[2] |
BUSHING
|
IH
meter wheel Superseded by part number: 668999R1
|
| 8. |
3102201R1
|
[1] |
WASHER
|
IH
rack retaining
|
| 9. |
3102111R4
|
[1] |
RACK
|
IH
GEAR, trip arm rack
|
| . . |
180121
|
[2] |
BOLT,Hex, 3/8" - 16 x 7/8", Gr 5
|
IH
3/8 x 7/8 type 5 Superseded by part number: 280643
|
| . . |
120394
|
[2] |
WASHER,3/8", SAE
|
IH
WASHER, .406 x .812 x .051 Superseded by part number: 87016
|
| . . |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 10. |
3102202R1
|
[1] |
WASHER
|
IH
rack retaining
|
| 11. |
103320
|
[1] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 12. |
179814
|
[1] |
SPACER
|
NNA
Superseded by part number: 13-510, 13-510, 80179814
|
| 13. |
3102978R1
|
[1] |
ROD
|
IH
trip
|
| 14. |
3102984R1
|
[1] |
BOLT
|
IH
5/16-18 x 3-3/4
|
| 15. |
120376
|
[1] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| 16. |
3102983R1
|
[1] |
BRACKET
|
IH
bale length control
|
| . . |
17351R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 crg type 1 Superseded by part number: 88682
|
| 17. |
477242R1
|
[1] |
WASHER
|
IH
13/32 x 1 x 22 ga
|
| 18. |
178375R1
|
[3] |
WASHER
|
IH
25/32 x 1-1/4 x 16 ga, (or as required) Superseded by part number: 249100
|
| . . |
3102979R91
|
[1] |
ARM
|
IH
ASSY, trip, consists 17, 19, 20, 22 thru 24
|
| 19. |
667811R1
|
[2] |
BUSHING
|
IH
trip arm
|
| 21. |
101330H
|
[1] |
SPRING
|
IH
trip
|
| 22. |
121222
|
[1] |
COTTER PIN,3/32" x 3/4"
|
IH
PIN, SPLIT (COTTER), 3/32" x 3/4" Superseded by part number: 132-321
|
| 23. |
662020R1
|
[1] |
STUD
|
IH
trip arm roller
|
| 24. |
662019R1
|
[1] |
ROLLER,28.57mm OD x 12.7mm L
|
IH
trip arm
|
| 25. |
204009C1
|
[1] |
SPRING
|
IH
trip rod
|
