纽荷兰零件查询(FD20) - CRAWLER DOZER (D2.27[001]) - PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1002 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 5106093. | 5106093 | [1] | COVER | MKT |
| 5120204. | 5120204 | [1] | COVER | MOD |
| 5120207. | 5120207 | [4] | BUSHING,10.5mm ID x 12.7mm OD x 19mm L | BAS |
| 5120647. | 5120647 | [1] | BODY | NH |
| 5120786. | 5120786 | [2] | BUSHING | MKT |
| 5120788. | 5120788 | [1] | FLANGE | NHCOVER |
| 5120789. | 5120789 | [1] | COVER | NH |
| 8273909. | 8273909 | [3] | O-RING,0.103" Thk x 1.862" ID, -134, Cl 5, 75 Duro | MOD Superseded by part number: 374545 |
| 8273912. | 8273912 | [4] | BUSHING | MKT Superseded by part number: 5120207 |
| 8273915. | 8273915 | [4] | NUT | MOD Superseded by part number: 12164721 |
| 8273916. | 8273916 | [4] | WASHER | MODLOCKWASHER Superseded by part number: 10516871 |
| 8281025. | 8281025 | [1] | GEAR | LECSET |
| 8281030. | 8281030 | [1] | BLOCK | LEC |
| 8281033. | 8281033 | [1] | BODY | MKT |
| 8281034. | 8281034 | [2] | SUPPORT | LEC |
| 8281201. | 8281201 | [3] | RUBBER RING | MODO-RING |
| 8281616. | 8281616 | [1] | KIT | LECCONSISTING OF… Superseded by part number: 8294907 |
| 8281617. | 8281617 | [2] | BUSHING | LEC |
| 8281620. | 8281620 | [1] | FLANGE | LECCOVER |
| 8281789. | 8281789 | [1] | BODY | MKT |
| 8283478. | 8283478 | [1] | COVER | MOD Superseded by part number: 5120204 |
| 8294814. | 8294814 | [1] | SPACER | LEC |
| 8294816. | 8294816 | [1] | GASKET | LECO-RING |
| 8294907. | 8294907 | [1] | KIT | LECCONSISTING OF… |
| 10516871. | 10516871 | [4] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 12164721. | 12164721 | [4] | NUT,M10 x 1.25, Cl 10 | TTF |
| 14458380. | 14458380 | [1] | O-RING,0.103" Thk x 1.299" ID, -125, Cl 5, 75 Duro | JES Superseded by part number: 130333 |
| 14460380. | 14460380 | [3] | O-RING,0.103" Thk x 2.55" ID, -145, Cl 5, 75 Duro | MKT Superseded by part number: 9672457 |
