纽荷兰零件查询(FD20) - CRAWLER DOZER (D2.27[002]) - PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
757 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 5106092. | 5106092 | [1] | COVER | MKT |
| 5120207. | 5120207 | [2] | BUSHING,10.5mm ID x 12.7mm OD x 19mm L | BAS |
| 5120785. | 5120785 | [1] | FLANGE | NHCOVER |
| 5120787. | 5120787 | [4] | SCREW | NH |
| 8273909. | 8273909 | [1] | O-RING,0.103" Thk x 1.862" ID, -134, Cl 5, 75 Duro | MOD Superseded by part number: 374545 |
| 8273911. | 8273911 | [1] | CIRCLIP | TTFLOCKRING |
| 8273912. | 8273912 | [2] | BUSHING | MKT Superseded by part number: 5120207 |
| 8273917. | 8273917 | [4] | WASHER | MODSEAL Superseded by part number: 10284460, 75225357 |
| 8273918. | 8273918 | [1] | KEY | TTFFEATHER KEY |
| 8273919. | 8273919 | [1] | NUT | TTF Superseded by part number: 8299236 |
| 8273920. | 8273920 | [1] | LOCK WASHER | TTFLOCKWASHER |
| 8280107. | 8280107 | [2] | SUPPORT | LEC |
| 8281201. | 8281201 | [1] | RUBBER RING | MODO-RING |
| 8281615. | 8281615 | [1] | GEAR | LECSET |
| 8281616. | 8281616 | [1] | KIT | LECCONSISTING OF… Superseded by part number: 8294907 |
| 8281618. | 8281618 | [3] | SCREW | LEC |
| 8281619. | 8281619 | [1] | SCREW | LEC |
| 8294816. | 8294816 | [2] | GASKET | LECSPACER |
| 8294905. | 8294905 | [1] | SPACER | LEC |
| 8294907. | 8294907 | [1] | KIT | LECCONSISTING OF… |
| 10284460. | 10284460 | [4] | WASHER,M10.2 x 16 x 1.5, Copper | IMOWASHER, SEALING, M10.2 x 16 x 1.5, Copper |
| 14460680. | 14460680 | [1] | O-RING,0.103" Thk x 2.737" ID, -148, Cl 5, 75 Duro | TTF-148, 90 Duro, 2.737" ID x .103" Thk |
