纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.02/5[001]) - HYDRAULIC SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
894 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 581658. | 581658 | [2] | PLUG | MOD Superseded by part number: 5116017 |
| 10516871. | 10516871 | [16] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 10517171. | 10517171 | [4] | LOCK WASHER,14.2mm ID x 24.1mm OD x 3.5mm Thk | MKTLOCKWASHER Superseded by part number: 10572074 |
| 11107331. | 11107331 | [16] | SCREW,Hex, M10 x 55mm, Cl 10.9 | LEC |
| 11112231. | 11112231 | [4] | SCREW,Hex, M12 x 1.75 x 25mm, Cl 10.9, Full Thd | LEC Superseded by part number: 398792 |
| 14330260. | 2852057 | [2] | SEALING WASHER,M8 x 12 x 1 Thk | TOR |
| 14463380. | 14463380 | [4] | O-RING,0.139" Thk x 1.046" ID, -215, Cl 5, 75 Duro | MKT Superseded by part number: 17288781 |
| 76004970. | 76004970 | [2] | CYLINDER | LECOPERATING CYLINDER Superseded by part number: 76007438 |
| 76005000. | 76005000 | [1] | RIGID TUBE | LECLINE |
| 76005001. | 76005001 | [1] | RIGID TUBE | LECLINE |
| 76007438. | 76007438 | [2] | CYLINDER | LECOPERATING CYLINDER Superseded by part number: 76016790 |
| 76016790. | 76016790 | [2] | CYLINDER | TOROPERATING CYLINDER |
| 79024113. | 79024113 | [2] | CYLINDER | LECOPERATING CYLINDER Superseded by part number: 76007438, 76005000, 76005001 |
| 79025634. | 79025634 | [1] | RIGID TUBE | LECLINE |
| 79025635. | 79025635 | [1] | RIGID TUBE | LECLINE |
| 79033027. | 79033027 | [2] | FLEXIBLE HOSE | LECHOSE Superseded by part number: 79033080 |
| 79033031. | 79033031 | [2] | HOSE | LEC Superseded by part number: 79033087 |
| 79034683. | 79034683 | [1] | RIGID TUBE | LECLINE Superseded by part number: 76005767 |
