纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.02/6[001]) - HYDRAULIC SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
619 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8284822. | 8284822 | [1] | SHIELD | LECPROTECTION |
| 8284838. | 8284838 | [1] | RIGID TUBE | LECPIPE |
| 8287762. | 8287762 | [4] | BLOCK | LECPAD |
| 8288426. | 8288426 | [1] | CYLINDER | LEC |
| 8295866. | 8295866 | [2] | HYD CONNECTOR | LECCONNECTION |
| 10263360. | 10263360 | [2] | SEAL,20.3mm ID x 26mm OD x 1mm Thk | TTFWASHER, SEALING, , Copper M20.3 x 26 x 1 |
| 10517077. | 10517077 | [6] | LOCK WASHER | MODLOCKWASHER Superseded by part number: 10517071 |
| 15540921. | 15540921 | [4] | SCREW,Hex, M12 x 1.25 x 55mm, Cl 8.8 | TTFBOLT, Hex, M12 x 1.25 x 55, 8.8 Superseded by part number: 15540924 |
| 15541021. | 15541021 | [2] | SCREW,Hex, M12 x 1.25 x 60mm, Cl 8.8 | TTF Superseded by part number: 15541024 |
| 79033075. | 79033075 | [2] | FLEXIBLE HOSE | LECHOSE |
