纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.02/8[001]) - RIPPER MOUNTS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
636 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4957707. | 4957707 | [20] | SCREW | LEC |
| 8294861. | 8294861 | [2] | PIN | LEC Superseded by part number: 8280513 |
| 10517270. | 10517270 | [16] | LOCK WASHER,16.2mm ID x 27.7mm OD x 4mm Thk | MKTLOCKWASHER Superseded by part number: 10517271 |
| 11195070. | 11195070 | [20] | LOCK WASHER | MKTLOCKWASHER Superseded by part number: 11195071 |
| 113376221. | 11376237 | [12] | BOLT,Hex, M16 x 1.5 x 35mm, Cl 8.8 | LEC |
| 11390521. | 11390521 | [4] | BOLT,Hex, M16 x 1.5 x 40, 8.8, Full Thd | TTF Superseded by part number: 11390531 |
| 13407211. | 13407211 | [5] | LUBE NIPPLE,M10 x 1 | TTFNIPPLE, LUBE, M10 x 1 Superseded by part number: 84351730 |
| 79025552. | 79025552 | [1] | SUPPORT | LEC |
| 79025557. | 79025557 | [2] | PIN | LEC Superseded by part number: 79025555 |
| 79025559. | 79025559 | [1] | PIN | LEC Superseded by part number: 79025560 |
| 79025565. | 79025565 | [2] | PLATE | LEC |
