纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.13/1[001]) - RIPPER TEETH New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
847 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8281294. | 8281294 | [3] | ROLL PIN | LECPIN Superseded by part number: 79057837 |
| 8281295. | 8281295 | [3] | SLEEVE | LEC Superseded by part number: 79057838 |
| 8284340. | 8284340 | [3] | PIN | LEC |
| 8284341. | 8284341 | [3] | RING | LEC |
| 15541621. | 15541621 | [3] | SCREW,Hex, M12 x 1.25 x 100mm, Cl 8.8 | TTFBOLT, Hex, M12 x 1.25 x 100, 8.8 Superseded by part number: 15541624 |
| 16105011. | 16105011 | [3] | NUT | ZEDNUT Superseded by part number: 16105021 |
| 79023544. | 79023544 | [3] | POINT | LECLUG Superseded by part number: 77903314 |
| 79025657. | 79025657 | [3] | RIPPER TOOTH | LECLUG |
