纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.15/3[001]) - IMPLEMENT CONTROL SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
211 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4985147. | 4985147 | [1] | HANDLE GRIP | LECHANGRIP |
| 8299095. | 8299095 | [1] | SPRING | LEC |
| 10205910. | 10205910 | [1] | KEY,5 x 9mm | TORFEATHER KEY Superseded by part number: 17221220 |
| 10516671. | 10516671 | [1] | LOCK WASHER | BHBLOCKWASHER Superseded by part number: 83990583 |
| 10516871. | 10516871 | [2] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 11106031. | 11106031 | [2] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9 | LECBOLT, Hex, M10 x 20, 10.9, Full Thd |
| 12646801. | 12646824 | [2] | WASHER,10.2mm ID x 25mm OD x 2mm Thk | TTF |
| 14162270. | 14162270 | [1] | LOCK PIN,M3 x 28, Slotted | TTFTAPER PIN |
| 14601270. | 14601270 | [2] | ROLL PIN,M5 x 28, Slotted | LECTAPER PIN |
| 16044131. | 16044131 | [1] | BOLT,Hex, M8 x 45mm, Cl 10.9 | LECBOLT, Hex, M8 x 45, 10.9 |
| 16100821. | 16100821 | [1] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 76005201. | 76005201 | [1] | SUPPORT | LEC |
| 79006928. | 79006928 | [1] | LEVER | LEC |
| 79028262. | 79028262 | [1] | LEVER | LEC |
| 79033126. | 79033126 | [1] | HUB | LEC |
| 79033661. | 79033661 | [1] | RING | LEC |
| 79033674. | 79033674 | [1] | SPRING | LEC |
