纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.25[001]) - IMPLEMENT CONTROL SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1012 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4985147. | 4985147 | [1] | HANDLE GRIP | LECKNOB |
| 8294287. | 8294287 | [3] | SPACER | LEC |
| 8296248. | 8296248 | [1] | HUB | LEC |
| 8296250. | 8296250 | [1] | SPACER | LEC |
| 8296251. | 8296251 | [1] | LINK/SHACKLE | LECSHACKLE |
| 8296252. | 8296252 | [1] | SCREW | LEC |
| 8296255. | 8296255 | [1] | LINK/SHACKLE | LECSHACKLE |
| 8296256. | 8296256 | [1] | SCREW | LEC |
| 8296257. | 8296257 | [1] | LINK/SHACKLE | LECSHACKLE |
| 8296429. | 8296429 | [1] | HUB | LEC |
| 8296430. | 8296430 | [2] | BUSHING | LECBUSH |
| 8296431. | 8296431 | [1] | PIN | LEC |
| 8296635. | 8296635 | [1] | LEVER | LEC |
| 8298318. | 8298318 | [1] | TERMINAL | LECTIEROD HEAD |
| 8298319. | 8298319 | [1] | TERMINAL | LECTIEROD HEAD |
| 8298461. | 8298461 | [1] | TIE-ROD | LECTIEROD |
| 8299252. | 8299252 | [1] | HUB | LEC Superseded by part number: 8296429 |
| 10205920. | 10205920 | [2] | WOODRUFF KEY,5mm x 9mm x 21.63mm | MKTKEY Superseded by part number: 17221220 |
| 10516671. | 10516671 | [2] | LOCK WASHER | BHBLOCKWASHER Superseded by part number: 83990583 |
| 10516871. | 10516871 | [2] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 10788721. | 10788721 | [2] | THIN NUT,Thin, M10 x 1.5, Cl 05 | LEC |
| 11106831. | 11106831 | [1] | SCREW,Hex, M10 x 40mm, Cl 10.9, Full Thd | LEC Superseded by part number: 11106821 |
| 11107031. | 11107031 | [1] | BOLT,Hex, M10 x 45mm, Cl 10.9 | LEC Superseded by part number: 86508618 |
| 11690921. | 11690921 | [1] | NUT,Thin, M10 x 1.5, Cl 04, LH | LEC |
| 14164270. | 14164270 | [1] | LOCK PIN,M4 x 28, Slotted | MKTPIN Superseded by part number: 14164370 |
| 16044131. | 16044131 | [2] | BOLT,Hex, M8 x 45mm, Cl 10.9 | LECBOLT, Hex, M8 x 45, 10.9 |
| 16108821. | 16100821 | [2] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
