纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.25/1[001]) - IMPLEMENT CONTROL SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
575 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 586707. | 586707 | [1] | SCREW | MOD |
| 4985147. | 4985147 | [1] | HANDLE GRIP | LECKNOB |
| 10205920. | 10205920 | [1] | WOODRUFF KEY,5mm x 9mm x 21.63mm | MKTKEY Superseded by part number: 17221220 |
| 10516671. | 10516671 | [1] | LOCK WASHER | BHBLOCKWASHER Superseded by part number: 83990583 |
| 10516871. | 10516871 | [2] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 11106231. | 11106231 | [2] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 | LECBOLT, Hex, M10 x 25, 10.9, Full Thd |
| 11106631. | 11106631 | [2] | SCREW,Hex, M10 x 35mm, Cl 10.9, Full Thd | LEC Superseded by part number: 86624978 |
| 11701721. | 11701721 | [2] | NUT,M10, Cl 10 | LEC Superseded by part number: 17038131 |
| 16044131. | 16044131 | [1] | BOLT,Hex, M8 x 45mm, Cl 10.9 | LECBOLT, Hex, M8 x 45, 10.9 |
| 16100821. | 16100821 | [1] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 76004972. | 76004972 | [1] | BRACKET | LEC(METAL SHEET) |
| 79005584. | 79005584 | [2] | BUSHING | LECBUSH |
| 79022297. | 79022297 | [1] | LEVER | LEC |
| 79022298. | 79022298 | [1] | LEVER | LEC |
| 79022303. | 79022303 | [1] | SUPPORT | LEC |
| 79022305. | 79022305 | [1] | YOKE | LECHUB |
| 79025365. | 79025365 | [1] | TOOTHED SECTOR | LECREFERENCE SECTOR |
| 79030543. | 79030543 | [1] | SUPPORT | LEC |
| 79030547. | 79030547 | [1] | LEVER | LEC |
| 79030550. | 79030550 | [1] | BRACKET | LEC(METAL SHEET) Superseded by part number: 76004972 |
