纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.31/A[002]) - CYLINDER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
719 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8286438. | 8286438 | [1] | GASKET | LECSEAL |
| 8287191. | 8287191 | [1] | NUT | LEC |
| 8288804. | 8288804 | [1] | SEAL,68mm ID x 73.6mm OD x 5.9mm Thk | LECMUDSCRAPER RING |
| 8288805. | 8288805 | [1] | PLATE | LECEND PLATE |
| 8288806. | 8288806 | [2] | BUSHING | LEC |
| 8288807. | 8288807 | [1] | SPACER | LEC |
| 8288808. | 8288808 | [1] | RING | LECRETAINER |
| 8289574. | 8289574 | [1] | BEARING ASSY | MKTBEARING Superseded by part number: 76004446 |
| 8291504. | 8291504 | [1] | SEAL | LECSEAL |
| 8293555. | 8293555 | [1] | BARREL | LEC |
| 8293556. | 8293556 | [1] | BARREL | LEC |
| 8293559. | 8293559 | [1] | ROD | LEC |
| 8293561. | 8293561 | [1] | WASHER | LEC |
| 8293562. | 8293562 | [1] | PLATE | LEC |
| 8299928. | 8299928 | [6] | HYDRAULIC VALVE | LECVALVE |
| 11062176. | 11062176 | [1] | CIRCLIP,M85, Int | TTFRING, LOCKING, M85, Int Superseded by part number: 370021 |
| 11062976. | 11062976 | [2] | SNAP RING,Int, M100 x 3 | TTFRING, LOCKING, Int, M100 x 3 Superseded by part number: S301572 |
| 13407211. | 13407211 | [2] | LUBE NIPPLE,M10 x 1 | TTFNIPPLE, LUBE, M10 x 1 Superseded by part number: 84351730 |
| 14272030. | 14272030 | [4] | SCREW | MKT Superseded by part number: 14272031 |
| 14466780. | 14466780 | [1] | GASKET,0.139" Thk x 4.859" ID, -249, Cl 5, 75 Duro | MKTSEAL Superseded by part number: 216255 |
| 76004446. | 76004446 | [1] | SPHERICAL BEARING,40mm ID x 100mm OD x 58mm W | LECBEARING |
| 79021442. | 79021442 | [1] | PISTON | LEC |
