纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.32/1[001]) - CYLINDER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
952 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8292259. | 8292259 | [1] | NUT | LEC |
| 8292367. | 8292367 | [1] | SEAL,115mm ID x 140mm OD x 25.4mm Thk | LECPISTON RING |
| 8298265. | 8298265 | [1] | RING | LECRETAINING RING |
| 10572271. | 10572271 | [6] | LOCK WASHER,M18 | MKTLOCKWASHER Superseded by part number: |
| 14467080. | 14467080 | [1] | O-RING,0.139" Thk x 5.234" ID, -252, Cl 5, 75 Duro | LEC-252, 70 Duro, 5.234" ID x .139" Thk Superseded by part number: 79051081 |
| 16040031. | 16040031 | [6] | BOLT,Hex, M18 x 90mm, Cl 10.9 | CMISCREW Superseded by part number: 16040037 |
| 76005007. | 76005007 | [1] | ROD | LECPISTON ROD |
| 79024057. | 79024057 | [1] | BRAKE LINING | LECMUDSCRAPER RING Superseded by part number: 79065575 |
| 79024058. | 79024058 | [1] | RING | LEC Superseded by part number: 79065576 |
| 79024059. | 79024059 | [1] | GASKET | LECMUDSCRAPER RING Superseded by part number: 79065577 |
| 79024117. | 79024117 | [1] | BASE PLATE | LECBOTTOM PLATE Superseded by part number: 79047730 |
| 79024122. | 79024122 | [1] | PISTON | LEC |
| 79035339. | 79035339 | [1] | BARREL | LEC |
| 79035343. | 79035343 | [1] | ROD | LECPISTON ROD |
| 79038369. | 79038369 | [1] | BASE PLATE | LECBOTTOM PLATE Superseded by part number: 79047730 |
| 79038370. | 79038370 | [1] | PISTON | LEC |
| 79047730. | 79047730 | [1] | BASE PLATE | LECBOTTOM PLATE Superseded by part number: 76016682 |
