纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.32/1B[001]) - CYLINDER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
830 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8284647. | 8284647 | [1] | GASKET | MODO-RING |
| 8284648. | 8284648 | [1] | BUSHING | LEC |
| 8284653. | 8284653 | [4] | SCREW | LEC |
| 8284681. | 8284681 | [1] | SPECIAL TOOL | LECFLANGE |
| 8291836. | 8291836 | [1] | SEAL | LECMUDSCRAPER RING Superseded by part number: 79065583 |
| 8292259. | 8292259 | [1] | NUT | LEC |
| 8292270. | 8292270 | [1] | BASE PLATE | LECBOTTOM PLATE |
| 8292271. | 8292271 | [2] | RING | LECGUIDE BUSHING Superseded by part number: 76016275 |
| 8292272. | 8292272 | [1] | PISTON | LEC |
| 8292273. | 8292273 | [1] | GASKET | LECMUDSCRAPER RING |
| 8292274. | 8292274 | [1] | SEAL,6.99mm Thk x 166.7mm ID | LECO-RING |
| 8292275. | 8292275 | [1] | SEAL,155mm ID x 177.1mm OD x 50.8mm Thk | LECO-RING |
| 8292276. | 8292276 | [1] | RING | LECRETAINING RING Superseded by part number: 45023401 |
| 8292277. | 8292277 | [1] | SPACER | LEC |
| 8294368. | 8294368 | [1] | BARREL | LEC |
| 8294372. | 8294372 | [1] | ROD | LECPISTON ROD |
| 10572371. | 10572371 | [4] | LOCK WASHER,M20 | TTFWASHER, LOCK, M20 Superseded by part number: |
| 11062976. | 11062976 | [1] | SNAP RING,Int, M100 x 3 | TTFRING, LOCKING, Int, M100 x 3 Superseded by part number: S301572 |
| 16050831. | 16050831 | [4] | BOLT,Hex, M20 x 90mm, Cl 10.9 | LECSCREW Superseded by part number: 9846950 |
| 76004453. | 76004453 | [1] | ENGINE CYLINDER LINER | LECBARREL |
| 76004456. | 76004456 | [1] | ROD | LECPISTON ROD |
| 76004457. | 76004457 | [1] | BASE PLATE | LECBOTTOM PLATE Superseded by part number: 79038923 |
| 76004460. | 76004460 | [1] | FLANGE | LEC |
| 76005029. | 76005029 | [1] | ROD | LECPISTON ROD |
| 76007444. | 76007444 | [1] | BASE PLATE | LECBOTTOM PLATE Superseded by part number: 76016681 |
| 79031332. | 79031332 | [1] | NUT | LEC Superseded by part number: 71320595 |
| 79031333. | 79031333 | [1] | O-RING | LEC Superseded by part number: 71316279 |
| 79031336. | 79031336 | [1] | O-RING | LECRING Superseded by part number: 79065582 |
| 79038923. | 79038923 | [1] | BASE PLATE | LECBOTTOM PLATE Superseded by part number: 76007444 |
