纽荷兰零件查询(FD20) - CRAWLER DOZER (E3.32/2[001]) - CYLINDER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
490 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8284648. | 8284648 | [1] | BUSHING | LEC |
| 8292272. | 8292272 | [1] | PISTON | LEC |
| 8292274. | 8292274 | [1] | SEAL,6.99mm Thk x 166.7mm ID | LECO-RING |
| 8292275. | 8292275 | [1] | SEAL,155mm ID x 177.1mm OD x 50.8mm Thk | LECO-RING |
| 8292276. | 8292276 | [1] | RING | LECRETAINING RING Superseded by part number: 45023401 |
| 10572371. | 10572371 | [4] | LOCK WASHER,M20 | TTFWASHER, LOCK, M20 Superseded by part number: |
| 16050831. | 16050831 | [4] | BOLT,Hex, M20 x 90mm, Cl 10.9 | LECSCREW Superseded by part number: 9846950 |
| 76004453. | 76004453 | [1] | ENGINE CYLINDER LINER | LECBARREL |
| 76004460. | 76004460 | [1] | FLANGE | LEC |
| 76005029. | 76005029 | [1] | ROD | LECPISTON ROD |
| 76016681. | 76016681 | [1] | BASE PLATE | LECBOTTOM PLATE |
| 79031332. | 79031332 | [1] | NUT | LEC Superseded by part number: 71320595 |
| 79065581. | 79065581 | [1] | SEAL,90mm ID x 110mm OD x 12mm Thk | TORO-RING |
| 79065582. | 79065582 | [1] | GASKET,89.5mm ID x 108.5mm OD x 5mm Thk | LECRING |
| 79065583. | 79065583 | [1] | SEAL,90mm ID x 110.25mm OD x 10mm Thk | LECMUDSCRAPER RING |
