| 1. |
662144R1
|
[1] |
STRAP
|
IH
hitch clevis upper
|
| 2. |
662145R1
|
[1] |
STRAP
|
IH
hitch clevis lower
|
| . . |
413-1036
|
[1] |
BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5
|
CAS
SCREW, 5/8-11 x 2-1/4 hex-hd cap Superseded by part number: 88556
|
| . . |
413-1044
|
[1] |
BOLT,Hex, 5/8" - 11 x 2-3/4", Gr 5
|
CAS
SCREW, 5/8-11 x 2-3/4 hex-hd cap, 1 for 440 Balers, 2 for 430 Balers Superseded by part number: 88693
|
| . . |
9413960
|
[2] |
LOCK NUT,5/8"-11, GB
|
IH
NUT, 5/8-11 PHC hex. Superseded by part number: 85700693
|
| . . |
103325
|
[2] |
LOCK WASHER,5/8"
|
IH
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 3. |
668406R91
|
[1] |
|
P
PIN ASSY, hitch, for 430 Baler, two knuckle PTO pkg
|
| 4. |
667608R92
|
[1] |
SPARE PART
|
IH
HITCH ASSY, for 440 Baler Superseded by part number: 667608R93
|
| 4. |
674105R1
|
[1] |
|
P
HITCH ASSY, for 430 Baler
|
| 5. |
668037R1
|
[1] |
SUPPORT
|
IH
rope, used w/3 knuckle drive shaft
|
| . . |
589068R1
|
[1] |
WASHER
|
IH
21/32 x 1-1/4 x 11 ga C-z Superseded by part number: 495-51066
|
| 7. |
674109R2
|
[1] |
PLATE
|
IH
hitch support, for 440 Baler
|
| 7. |
674108R2
|
[1] |
SUPPORT
|
IH
PLATE, hitch support, for 430 Baler
|
| . . |
15010R1
|
[1] |
CARRIAGE BOLT,Short Sq Nk, 1/2" - 13 x 1", Gr 2
|
IH
BOLT, 1/2 x 1 sq-nk crg
|
| . . |
664573R1
|
[1] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2-13 hex. lock Superseded by part number: 231-4218
|
| . . |
103323
|
[1] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| . . |
271556
|
[5] |
WHEEL CYLINDER,Hex, 5/8" - 11 x 1 1/4", Gr 5
|
IH
SCREW, 5/8-11 x 1-1/4 hex-hd cap
|
| . . |
667927R1
|
[5] |
LOCK NUT,5/8"-11, GB
|
IH
NUT, 5/8-11 hex. lock Superseded by part number: 231-42110
|
| . . |
366866C1
|
[5] |
LOCK WASHER,5/8"
|
IH
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 8. |
667622R2
|
[1] |
LEVER
|
IH
hitch
|
| 9. |
667923R1
|
[1] |
SLIDE
|
IH
PIVOT, hitch lever
|
| . . |
17768R1
|
[1] |
BOLT,Hex, 1/2" - 13 x 4 1/2", Gr 2
|
IH
1/2 x 4-1/2 hex-hd mach Superseded by part number: 190256
|
| . . |
178373R1
|
[2] |
WASHER
|
IH
17/32 x 1 x 16 ga C-Z Superseded by part number: 495-51053
|
| 10. |
165
|
[1] |
SPRING
|
IH
hitch lever Superseded by part number: 165-2
|
| . . |
21644R1
|
[1] |
PIN,1/4" x 1"
|
IH
Split (Cotter), 1/4" x 1" Superseded by part number: 87401
|
| . . |
18481R1
|
[1] |
COTTER PIN,3/16" x 1"
|
IH
PIN, SPLIT (COTTER), 3/16" x 1" Superseded by part number: 432-1216
|
| 11. |
674110R1
|
[1] |
PIVOT
|
IH
ASSY, hitch
|
| . . |
179860
|
[2] |
BOLT,Hex, 7/16" - 14 x 1 1/4", Gr 5
|
IH
SCREW, 7/16-14 x 1-1/4 znd hex-hd cap Superseded by part number: 9627887
|
| . . |
664646R1
|
[2] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 hex. lock Superseded by part number: 280980
|
| . . |
103322
|
[2] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
LOCK, Ext Tooth, 7/16"
|
| . . |
662560R1
|
[1] |
BOLT,Hex, 1" - 14 x 6 1/2"
|
IH
1-14 x 6-1/2 C-Z hitch anchor
|
| . . |
70121D
|
[1] |
NUT
|
IH
1-14 hex. slt jam Superseded by part number: 143183
|
| . . |
21162R1
|
[1] |
WASHER
|
IH
1-1/32 x 2 x 7 ga C-Z Superseded by part number: 86900677
|
| . . |
125637
|
[1] |
COTTER PIN,1/8" x 2"
|
IH
PIN, SPLIT (COTTER), 1/8" x 2" Superseded by part number: 86523955
|
| . . |
21213R1
|
[1] |
WASHER
|
IH
1-1/32 x 2 x 11 ga C-Z Superseded by part number: 495-81077
|
| 12. |
667628R1
|
[1] |
ANGLE
|
IH
STRAP, anchor hitch pivot
|
| . . |
413-1032
|
[2] |
BOLT,Hex, 5/8" - 11 x 2", Gr 5
|
CAS
SCREW, 5/8-11 x 2 znd hex-hd cap Superseded by part number: 86505999
|
| . . |
425-110
|
[2] |
5/8-18 C-Z hex.
|
|
| . . |
492-11062
|
[2] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| . . |
138557
|
[2] |
WASHER,Int Tooth, 5/8"
|
IH
5/8 C-Z int-tooth lock Superseded by part number: 138559
|
| 13. |
204109C1
|
[1] |
BRACKET
|
IH
ASSY, hitch support, for 440 Baler
|
| 13. |
667620R2
|
[1] |
BRACKET
|
IH
hitch support, for 430 Baler
|
| . . |
17473R1
|
[4] |
BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 2
|
IH
1/2 x 1-1/2 hex-hd mach Superseded by part number: 87689
|
| 14. |
668758R1
|
[1] |
SPACER
|
IH
hitch plate
|
| 15. |
673164R1
|
[1] |
EXTENSION
|
IH
SECTION ASSY, hitch extension, used w/3 knuckle drive shaft for 430 Baler Superseded by part number: 3101505R1
|
| . . |
21759R1
|
[2] |
WASHER
|
IH
21/32 x 2 Superseded by part number: 106267
|
| 16. |
671095R91
|
[1] |
CHANNEL
|
IH
ASSY, hitch extension, used w/3 knuckle drive shaft for 430 Baler Superseded by part number: 671095R92
|
| 17. |
517843R1
|
[2] |
COTTER PIN
|
IH
PIN, 3/16 quick attachable cot., 440 Balers, 430 Balers three knuckle PTO pkg, use for two knuckle PTO pkg Superseded by part number: 86000109
|
| . . |
22106R1
|
[1] |
HEADED PIN,3/4" x 3 3/4"
|
CAS
PIN, 3/4 x 3-3/4 std, 440 and 430 Balers three knuckle PTO pkg Superseded by part number: 439-11260
|
