| 1. |
674485R3
|
[1] |
|
P
CHAMBER ASSY, bale
|
| . . |
550796R1
|
[2] |
CARRIAGE BOLT,3/8" - 16 x 1 1/4", Grade 5
|
IH
BOLT, 3/8-16 x 1-1/4 znp sq-nk crg type 2 Superseded by part number: 86508749
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
469668R1
|
[2] |
WASHER
|
IH
13/32 x 3/4 x 16 ga znp Superseded by part number: 86632580
|
| 2. |
667684R2
|
[1] |
KNIFE
|
IH
hay Superseded by part number: 203021C1
|
| . . |
15588R1
|
[3] |
PLOW BOLT,#3, 5/8" - 11 x 1 1/2", Gr 2
|
IH
BOLT, PLOW, , Patent Hd 5/8"-11 x 1 1/2", G2, Full Thd
|
| . . |
121358
|
[3] |
YOKE
|
NNA
5/8-18 C-Z hex. Superseded by part number: 425-1110, 425-1110, NLS
|
| . . |
492-11062
|
[3] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 3. |
667683R21
|
[1] |
SUPPORT
|
IH
twister RH, for wire balers
|
| . . |
17351R1
|
[3] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 znp sq-nk crg Superseded by part number: 88682
|
| 4. |
662294R3
|
[1] |
PLATE
|
IH
hay retainer RH
|
| . . |
18508R1
|
[1] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 znd sq-nk crg, 3 for twine Balers, 1 for wire Balers Superseded by part number: 86508748
|
| 5. |
662147R4
|
[1] |
ANCHOR
|
IH
bale tension channel
|
| . . |
18495R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 2
|
IH
3/8 x 1-1/4 znp hex-hd mach Superseded by part number: 180124
|
| . . |
18494R1
|
[4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
3/8 x 1 znd hex-hd mach Superseded by part number: 424-616
|
| 6. |
5179PA
|
[4] |
WEDGE
|
IH
hay retainer
|
| 7. |
204044C1
|
[1] |
CHAIN (AG)
|
IH
CHAIN, bale chamber ext hold-up, when ordered Superseded by part number: 495526R1
|
| . . |
598804R1
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1 1/4", Gr 5
|
IH
BOLT, 5/16 x 1-1/4 znd sq-nk crg Superseded by part number: 280827
|
| . . |
120376
|
[2] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
668569R1
|
[1] |
WASHER
|
IH
11/32 x 1-1/2 x 11 ga znd Superseded by part number: 87020812
|
| . . |
619855R1
|
[2] |
WASHER
|
IH
11/32 x 3/4 x 16 ga znd Superseded by part number: 86637953
|
| . . |
80681
|
[1] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 8. |
667693R1
|
[1] |
EXTENSION
|
IH
bale chamber, when ordered, 430T Balers 012280 and below, 430W Balers 001778 and below, 440T Balers 004613 and below, 440W Balers 002483 and below
|
| 8. |
204043C1
|
[1] |
EXTENSION
|
IH
bale chamber, 430T Balers 012281 and up, 430W Balers 001779 and up, 440T Balers 004614 and up, 440W Balers 002484 and up
|
| . . |
20485R1
|
[2] |
BOLT,Short NK, 7/16"-14 x 3/4", G5. Full Thd
|
IH
7/16 x 3/4 C-Z sq-nk crg
|
| . . |
473213R1
|
[2] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 C-Z hex. lock Superseded by part number: 280980
|
| . . |
21331R1
|
[2] |
WASHER
|
IH
15/32 x 1-1/4 x 16 ga C-Z Superseded by part number: 106265
|
| 9. |
662007R2
|
[2] |
RETAINER
|
IH
hay
|
| 10. |
668869R1
|
[2] |
SPRING
|
IH
hay retainer
|
| 11. |
667681R21
|
[1] |
|
P
SUPPORT, twister LH, for wire Balers
|
| . . |
619856R1
|
[1] |
WASHER
|
IH
13/32 x 1 x 16 ga znp Superseded by part number: 87613182
|
| 12. |
671960R2
|
[1] |
PLATE
|
IH
hay retainer left
|
| 13. |
667685R1
|
[1] |
PIN
|
IH
hay retainer
|
| . . |
187988
|
[2] |
COTTER PIN,3/16" x 1 1/4"
|
IH
PIN, SPLIT (COTTER), 3/16" x 1 1/4" Superseded by part number: 87398
|
| 14. |
203187C1
|
[1] |
HOLDER
|
IH
chain, replaces 754484R1
|
| . . |
18421R1
|
[1] |
CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2
|
IH
BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G5, Full Thd Superseded by part number: 412-716
|
| 15. |
203016C1
|
[2] |
SHIM
|
IH
stationary knife, .020, (or as required)
|
| 15. |
203017C1
|
[1] |
SHIM
|
IH
stationary knife .010, (or as required), 430T Balers 009786 and up, 430W Balers 001504 and up, 440T Balers 003570 and up, 440W Balers 002029 and up
|
