| 1. |
674267R1
|
[1] |
CHANNEL
|
IH
ASSY, axle, for 440 Baler Superseded by part number: 674267R2
|
| 1. |
674274R1
|
[1] |
|
P
CHANNEL ASSY, axle, for 430 Baler, 430T Balers 012280 and below, 430W Balers 001778 and below
|
| 1. |
204027C1
|
[1] |
|
P
CHANNEL ASSY, axle, for 430 Balers, 430T Balers 012281 and up, 430W Balers 001779 and up
|
| . . |
18794R1
|
[2] |
BOLT,Hex, 7/16" - 14 x 1", Gr 2
|
IH
7/16 x 1 C-Z hex-hd mach Superseded by part number: 9706729
|
| . . |
271501
|
[2] |
SOCKET
|
NNA
NUT, 7/16-14 C-Z hex.
|
| . . |
120383
|
[2] |
LOCK WASHER,Helical Spring, 7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 2. |
662148R1
|
[1] |
GUSSET
|
IH
axle RH
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
NUT, 7/16-14 C-Z hex.
|
| 3. |
674278R1
|
[1] |
BRACE
|
IH
ASSY, diagonal
|
| . . |
18494R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
3/8 x 1 C-Z hex-hd mach Superseded by part number: 424-616
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 4. |
674281R1
|
[1] |
BRACKET
|
IH
diagonal brace
|
| . . |
17351R1
|
[4] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 C-Z sq-nk crg Superseded by part number: 88682
|
| 5. |
674282R2
|
[1] |
SUPPORT
|
IH
ASSY, bale chamber Superseded by part number: 210565C1
|
| . . |
280954
|
[2] |
NUT,3/4"-10, G5
|
NH
|
| . . |
18573R1
|
[1] |
CARRIAGE BOLT,Short Sq Nk, 5/8" - 11 x 1 1/2", Gr 2
|
CAS
BOLT, 5/8 x 1-1/2 znd sq-nk crg Superseded by part number: 111-635
|
| . . |
280374
|
[1] |
NUT,Hex, 5/8" - 11, Gr 5
|
NH
5/8-11 znd hex.
|
| . . |
492-11062
|
[1] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
