| 1. |
674310R1
|
[1] |
SHIELD
|
IH
END, auger shield Superseded by part number: 210681C2
|
| 2. |
674311R1
|
[1] |
TOP
|
IH
auger shield
|
| . . |
137138
|
[4] |
SCREW,Sl Truss Hd, 1/4" - 20 x 3/4"
|
IH
1/4-20 x 3/4 C-Z slt-truss-hd mach
|
| . . |
120375
|
[4] |
NUT,Hex, 1/4" - 20, Gr 5
|
IH
Superseded by part number: 7770
|
| . . |
492-11025
|
[4] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| . . |
18764R1
|
[2] |
HARDWARE,Hex, 5/16"-18 x 3/4", G2
|
IH
BOLT, 5/16 x 3/4 C-Z hex-hd mach Superseded by part number: 424-512
|
| . . |
670472R1
|
[2] |
SPRING NUT,J, Ret, 5/16"-18
|
IH
5/16-18 speed grip Superseded by part number: 131-890
|
| . . |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 3. |
674312R1
|
[1] |
SHIELD
|
IH
auger rear
|
| . . |
674313R1
|
[2] |
|
P
NUT, 5/16-18 speed grip
|
| 4. |
662958R91
|
[1] |
PULLEY
|
IH
ASSY, idler
|
| 5. |
674768R1
|
[1] |
SPACER
|
IH
idler pulley Superseded by part number: M42297
|
| . . |
18723R1
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 2 3/4", Gr 2
|
IH
BOLT, 5/8 x 2-3/4 C-Z sq-nk crg Superseded by part number: 411-1044
|
| . . |
425-110
|
[1] |
5/8-18 C-Z hex.
|
|
| . . |
492-11062
|
[1] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| . . |
589068R1
|
[1] |
WASHER
|
IH
21/32 x 1-1/4 x 11 ga C-Z Superseded by part number: 495-51066
|
| 6. |
657160R1
|
[4] |
PULLEY
|
IH
SHEAVE, auger drive, 430T Balers 009785 and below, 430T Balers 001503 and below, 440T Balers 003569 and below, 440W Balers 002028 and below
|
| . . |
18765R1
|
[8] |
BOLT,Hex, 5/16" - 18 x 1 1/2", Gr 2
|
IH
5/16 x 1-1/2 C-Z hex-hd mach Superseded by part number: 180083
|
| . . |
120376
|
[8] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
619855R1
|
[24] |
WASHER
|
IH
11/32 x 3/4 x 16 ga C-Z Superseded by part number: 86637953
|
| 7. |
674305R1
|
[1] |
HOLDER
|
IH
BRACKET, auger idler pulley
|
| . . |
18787R1
|
[2] |
BOLT,Hex, 3/8"-16 x 4", G2
|
IH
3/8 x 4 C-Z hex-hd mach Superseded by part number: 186285
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 8. |
674309R1
|
[2] |
HUB
|
IH
V-sheave, 430T Balers 009785 and below, 430W Balers 001503 and below, 440T Balers 003569 and below, 440W Balers002028 and below
|
| . . |
17150R1
|
[2] |
PIN,5/16" x 1 3/8", Slotted
|
IH
Superseded by part number: 38-32022
|
| 9. |
495290R1
|
[2] |
BUSHING
|
IH
auger pivot relief, cane hay equip also
|
| 10. |
201653C2
|
[1] |
ARM
|
IH
ASSY, auger relief, replaces 674479R1, 430T Balers 009785 and below, 430W Balers 001503 and below, 440T Balers 003569 and below, 440W Balers 002028 and below
|
| 10. |
202888C1
|
[1] |
ARM
|
IH
ASSY, auger relief, 430T Balers 009786 and up, 430W Balers 001504 and up, 440T Balers 003570 and up, 440W Balers 002029 and up
|
| . . |
179897
|
[2] |
BOLT,Hex, 1/2" - 13 x 4", Gr 5
|
IH
SCREW, 1/2-13 x 4 hex-hd cap Superseded by part number: 86505993
|
| . . |
664573R1
|
[2] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2-13 hex lock Superseded by part number: 231-4218
|
| . . |
120384
|
[2] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| . . |
22191R1
|
[4] |
WASHER
|
IH
.531 x 1.750 x .164 znd Superseded by part number: 495-81164
|
| 11. |
87414
|
[2] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, 1/4-28 self tapping lub
|
| . . |
21784R1
|
[2] |
WASHER
|
IH
17/64 x 1/2 x 16 ga C-Z Superseded by part number: 86624137
|
| 12. |
674296R1
|
[1] |
PIPE
|
IH
ASSY, auger relief pivot, for 430 Baler, 430T Balers 009785 and below, 430W Balers 001503 and below
|
| 12. |
674299R1
|
[1] |
PIPE
|
IH
ASSY, auger relief pivot, for 440 Balers, 440T Balers 003569 and below, 440W Balers 002028 and below
|
| 12. |
203022C91
|
[1] |
PIPE
|
IH
ASSY, auger relief pivot, 430T Balers 009786 thru 012280, 430W Balers 001504 thru 001778
|
| 12. |
202891C1
|
[1] |
PIPE
|
IH
ASSY, auger relief pivot, 440T Balers 003570 and up, 440W Balers 002029 and up, 430T Balers 012281 and up, 430W Balers 001779 and up
|
| 13. |
495473R1
|
[1] |
BRACKET
|
IH
BEARING, auger relief RH
|
| . . |
18508R1
|
[2] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 C-Z sq-nk crg Superseded by part number: 86508748
|
| 14. |
667774R1
|
[1] |
COLLAR
|
IH
auger relief RH
|
| . . |
102872
|
[1] |
SET SCREW
|
IH
1/4-20 x 3/4 C-Z sq-hd cup-pt set Superseded by part number: 280194
|
| 15. |
112139
|
[3] |
WOODRUFF KEY,#A, 1/4" x 7/8"
|
IH
KEY, 1/4 x 7/8 Woodruff Superseded by part number: 280934
|
| 16. |
674298R1
|
[1] |
SHAFT
|
IH
auger drive, for 430 Balers, 430T Balers 012280 and below, 430W Balers 001778 and below
|
| 16. |
674301R1
|
[1] |
SHAFT
|
IH
auger drive, for 440 Balers, 430T Balers 012281 and up, 440W Balers 001779 and up
|
| 17. |
674308R1
|
[1] |
GEAR
|
IH
PINION, auger drive
|
| . . |
22753R1
|
[1] |
HEADED PIN,5/16" x 2 3/16"
|
IH
PIN, HEADED, 5/16" x 2 3/16"
|
| . . |
12860R1
|
[1] |
PIN
|
IH
1/8 x 1/2 znp cot. Superseded by part number: 80756
|
| . . |
20703R1
|
[7] |
WASHER
|
IH
29/32 x 1-3/4 x 16 ga C-Z, (or as required) Superseded by part number: 495-81059
|
| . . |
23365R1
|
[4] |
WASHER
|
IH
29/32 x 1-11/32 x 20 ga C-Z, (or as required)
|
| 18. |
674286R1
|
[1] |
AUGER
|
IH
ASSY, for 440 Balers, 430T Balers 012281 and up, 430W Balers 001779 and up
|
| 18. |
674290R1
|
[1] |
AUGER
|
IH
ASSY, for 430 Balers, 430T Balers 012281 and up, 430W Balers 001778 and below
|
| 18. |
202894C1
|
[1] |
AUGER
|
IH
ASSY, cane hay equip.
|
| 19. |
665187R1
|
[1] |
THRUST WASHER
|
IH
bronze
|
| 20. |
674292R1
|
[1] |
SPACER
|
IH
PIPE ASSY, auger core, for 430 Balers, 430T Balers 009785 and below, 430W Balers 001503 and below
|
| 20. |
202893C1
|
[1] |
PIPE
|
IH
ASSY, auger core, for 430 Balers, 430T Balers 009786 thru 012280, 430W Balers 001504 thru 001778
|
| 20. |
674294R1
|
[1] |
PIPE
|
IH
ASSY, auger core, for 440 Balers, 440T Balers 003569 and below, 440W Balers 002028 and below
|
| 20. |
203023C91
|
[2] |
PIPE
|
IH
ASSY, auger core, for 440 Balers, 440T Balers 003570 and up, 440W balers 002029 and up, 430T Balers 012281 and up, 430W Balers 001779 and up, cane hay equip
|
| 21. |
674307R1
|
[3] |
STOP
|
IH
auger
|
| 21. |
202896C1
|
[4] |
BLOCK
|
IH
SPACER, cane hay equip
|
| . . |
18775R1
|
[1] |
BOLT,Hex, 5/16"-18 x 5", G2
|
IH
5/16 x 5 C-Z hex-hd mach Superseded by part number: 88575
|
| . . |
632225R1
|
[1] |
LOCK NUT
|
IH
5/16-18 hex. lock Superseded by part number: 145458
|
| . . |
9412083
|
[1] |
NUT,5/16"-18, GB
|
IH
NUT, 5/16-18 cad hex lock, cane hay equip Superseded by part number: 9413994
|
| 22. |
674306R1
|
[2] |
STRAP
|
IH
auger guide
|
| 23. |
516694R1
|
[2] |
SPACER
|
IH
auger guide strap
|
| . . |
18511R1
|
[2] |
BOLT,Short NK, 3/8"-16 x 3", G2
|
IH
3/8 x 3 C-Z sq-nk crg Superseded by part number: 111-327
|
| . . |
124829
|
[2] |
JAM NUT,Hex, 3/8" - 16, Gr 5
|
IH
Superseded by part number: 329-146
|
| . . |
138542
|
[2] |
LOCK WASHER,Int Tooth, 3/8"
|
IH
WASHER, LOCK, Int Tooth, 3/8" Superseded by part number: 9672276
|
| . . |
21786R1
|
[2] |
SQ HOLE WASHER,13/32" x 2 3/8" x .120", Sq Hole
|
IH
13/32 x 2-3/8 x 11 ga C-Z sq hole
|
| 24. |
452864R1
|
[1] |
V-BELT
|
IH
Auger drive
|
| 25. |
674419R1
|
[1] |
SUPPORT
|
IH
auger shield
|
| . . |
12872R1
|
[2] |
BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd
|
IH
CARRIAGE, Short NK, 5/16"-18 x 1", G2, Full Thd Superseded by part number: 598803R1
|
| 26. |
674314R1
|
[1] |
SHIELD
|
IH
auger front
|
| 27. |
201906C1
|
[4] |
|
P
PLATE, bolt bearing, 430T Balers 009785 and below, 430W Balers 001503 and below, 440T Balers 003569 and below, 440W Balers 002028 and below
|
| . . |
366862C1
|
[8] |
LOCK WASHER,3/8"
|
IH
3/8" Superseded by part number: 80680
|
| . . |
186285
|
[8] |
BOLT,Hex, 3/8" - 16 x 4", Gr 5
|
IH
Superseded by part number: 80012047
|
| . . |
664645R1
|
[8] |
LOCK NUT,3/8"-16, GB
|
IH
NUT, 3/8-16 hex. lock Superseded by part number: 231-4206
|
| 28. |
202837C1
|
[2] |
PULLEY
|
IH
auger drive, 430T Balers 009786 and up, 430W Baler 001504 and up, 440T Balers 003570 and up, 440W Balers 002029 and up
|
| . . |
616253R1
|
[2] |
LOCK PIN,5/16" x 1 5/8", Slotted
|
IH
Pin, 5/16" x 1 5/8", Slotted Superseded by part number: 70921559
|
