纽荷兰零件查询(FD255) - CRAWLER DOZER (N.A. VERSION) (7/95-) (0.042[01]) - ENGINE OIL SUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
282 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 61316734 | [1] | SUMP | LEC |
| 2. | 4763177 | [1] | PLUG | LEC |
| 3. | 61835009 | [1] | PLUG | LEC |
| 4. | 10303460 | [1] | GASKET | LEC30X36X1,5 |
| 5. | 61319084 | [1] | GASKET | LEC |
| 6. | 10118811 | [1] | PLUG,M22 x 1.5 x 14, Cl5.8 | JES Superseded by part number: 221579A1 |
| 7. | 14438089 | [1] | GASKET | LEC2,4X19,3 Superseded by part number: 14438085 |
| 9. | 15971521 | [6] | SCREW,Hex, M10 x 1.25 x 85mm, Cl 8.8 | BAS Superseded by part number: 15971524 |
| 10. | 11198374 | [32] | BELLEVILLE WASHER,Belleville, M10.5 | TTF |
| 12. | 11198673 | [4] | LOCK WASHER | TTFM12 |
| 13. | 10276111 | [1] | PLUG,M32 x 1.5 x 15 | TOR32X1,5, Start Serial: D3747 Superseded by part number: 16993611 |
| 14. | 10265060 | [1] | SEALING WASHER,32.4mm ID x 38mm OD x 1.5mm Thk | TOR, Start Serial: D3747 |
| 15. | 1940142 | [1] | ENGINE GASKET KIT | LEC |
| 8. | 11234724 | [26] | BOLT,Hex, M10 x 1.25 x 45, 8.8 | TTF |
| 11. | 15540624 | [4] | BOLT,Hex, M12 x 1.25 x 40mm, Cl 8.8, Full Thd | TTF |
