纽荷兰零件查询(FD20) - CRAWLER DOZER (Z1.01/B[001]) - ACCESSORIES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
672 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10516471. | 10516471 | [2] | LOCK WASHER | BHBWASHER Superseded by part number: 86517328 |
| 10725911. | 10725911 | [2] | THIN NUT,Thin, M6 x 1, Cl 04 | MKT Superseded by part number: |
| 10725940. | 10725940 | [6] | NUT,Thin, M6 x 1, Brass | LEC |
| 10979440. | 10979440 | [1] | BOLT,Hex, M6 x 10mm, Brass, Full Thd | LECSCREW Superseded by part number: 378056 |
| 16038540. | 16038540 | [6] | BOLT,Hex, M6 x 100mm, Brass | LECSCREW |
| 45482314. | 45482314 | [2] | HYDRAULIC VALVE | TORVALVE |
| 71304372. | 71304372 | [1] | ECCENTRIC | TOR |
| 71304373. | 71304373 | [2] | HYD CONNECTOR | TORFITTING |
| 71304374. | 71304374 | [1] | BODY | TOR |
| 71304375. | 71304375 | [1] | O-RING | TOR Superseded by part number: 172033 |
| 71304377. | 71304377 | [1] | MEMBRANE | TOR |
| 71304378. | 71304378 | [1] | BODY | TOR |
| 71304379. | 71304379 | [1] | BODY | TOR |
| 71304380. | 71304380 | [2] | DISC | TORDISK |
| 71304381. | 71304381 | [1] | MEMBRANE | TOR |
| 71304385. | 71304385 | [1] | SUPPORT | TOR |
| 71304386. | 71304386 | [1] | COMMUTATOR BRUSH | TORBRUSH |
| 71304387. | 71304387 | [2] | COVER | TOR |
| 71304388. | 71304388 | [1] | SMALL ELECTRIC MOTOR | TORELECTRIC MOTOR |
| 71304389. | 71304389 | [1] | LINK CONROD | TORLINK |
| 79094911. | 79094911 | [4] | PLATE | LECSMALL DISK |
| 79094912. | 79094912 | [4] | SPRING | LEC |
