纽荷兰零件查询(FD255) - CRAWLER DOZER (N.A. VERSION) (7/95-) (0.071[01]) - INTAKE MANIFOLD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
910 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 61318946 | [1] | INLET MANIFOLD | LEC |
| 2. | 61321089 | [2] | GASKET | LECKLINGER |
| 3. | 61319021 | [2] | SCREW | LEC8X1,25X125 |
| 4. | 16044124 | [11] | BOLT,Hex, M8 x 1.25 x 45mm, Cl 8.8 | TTF |
| 5. | 11288024 | [12] | BOLT,Hex, M10 x 1.25 x 60mm, Cl 8.8 | TTF |
| 6. | 11198374 | [12] | BELLEVILLE WASHER,Belleville, M10.5 | TTF |
| 7. | 61318945 | [1] | INLET MANIFOLD | LEC |
| 8. | 61319093 | [1] | GASKET | LEC |
| 9. | 11193874 | [25] | BELLEVILLE WASHER,8.4mm ID x 16.00mm OD x 1.4mm, 1.85mm, Cl 8.8 | TTF |
| 10. | 16044621 | [4] | SCREW,Hex, M8 x 70mm, Cl 8.8 | TTF Superseded by part number: 16606524 |
| 11. | 13543324 | [4] | STUD | MKT8X1,25X16X20 Superseded by part number: 13543321 |
| 12. | 16100821 | [4] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 13. | LEC1940141 | [1] | ENGINE TOP GASKETS KIT | LEC |
| 13. | 1940142 | [1] | ENGINE GASKET KIT | LEC |
| 14. | 61316690 | [2] | FLANGE | LEC, Start Serial: D3747 |
| 15. | 61319094 | [2] | GASKET | LEC, Start Serial: D3747 |
| 16. | 14458081 | [2] | O-RING,1.112" ID x 0.103" Width | TTF, Start Serial: D3747 |
| 17. | 61321853 | [1] | SCREW | LEC, Start Serial: D3747 |
| 18. | 61321947 | [2] | SCREW | LEC, Start Serial: D3747 |
| 19. | 11903171 | [3] | PLUG | MOD10X1,25 Superseded by part number: 11903111 |
| 20. | 4858606 | [3] | SEAL,10.2mm ID x 16mm OD x 1mm Thk | TTF10X14X1 |
