纽荷兰零件查询(FD255) - CRAWLER DOZER (N.A. VERSION) (7/95-) (0.323[03]) - PIPING - ENGINE COOLING SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
145 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 61319931 | [1] | RIGID TUBE | LEC- DELIVERY |
| 2. | 61319096 | [1] | GASKET | LEC |
| 3. | 16043924 | [2] | BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8, Full Thd | TTF |
| 4. | 11193874 | [2] | BELLEVILLE WASHER,8.4mm ID x 16.00mm OD x 1.4mm, 1.85mm, Cl 8.8 | TTF |
| 5. | 61321890 | [1] | RIGID TUBE | LEC- RETURN, Start Serial: D3747 |
| 5. | 61321226 | [1] | RIGID TUBE | LEC- RETURN, Serial Range: -C3747 Superseded by part number: 61321890 |
| 6. | 98463349 | [4] | HOSE CLIP | LEC32-40 Superseded by part number: 18088692 |
| 7. | 99444726 | [2] | HOSE | LEC |
| 8. | 14458081 | [2] | O-RING,1.112" ID x 0.103" Width | TTF, Serial Range: -C3747 |
| 9. | 61316690 | [2] | FLANGE | LEC, Serial Range: -C3747 |
| 10. | 61319094 | [2] | GASKET | LEC, Serial Range: -C3747 |
| 11. | LEC1940141 | [1] | ENGINE TOP GASKETS KIT | LEC |
| 11. | 1940142 | [1] | ENGINE GASKET KIT | LEC |
