纽荷兰零件查询(FD255) - CRAWLER DOZER (N.A. VERSION) (7/95-) (9.470[02]) - TILT CYLINDER - FRONT IMPLEMENT - OPTIONAL CODE 76030395 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
514 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8284648 | [1] | BUSHING | LEC, Serial Range: -C3751 |
| 2. | 71446406 | [1] | BARREL | LEC, Serial Range: -C3751 |
| 3. | 79076431 | [1] | GASKET KIT | LEC, Serial Range: -C3751 |
| 4. | 71446279 | [1] | ROD | LEC, Serial Range: -C3751 |
| 5. | 76004460 | [1] | FLANGE | LEC, Serial Range: -C3751 |
| 6. | 71448458 | [1] | BASE PLATE | NH, Serial Range: -C3751 Superseded by part number: 71448548 |
| 7. | 71400722 | [1] | PISTON | LEC, Serial Range: -C3751 |
| 8. | 71400723 | [1] | SEAL | LEC, Serial Range: -C3751 |
| 9. | 71400094 | [1] | NUT | LEC, Serial Range: -C3751 |
| 10. | 11125434 | [6] | BOLT,Hex, M20 x 55, 10.9 | LEC20X2,5X85, Serial Range: -C3751 |
| 11. | 79102350 | [1] | SCREW,M10 x 1.25 x 15mm | LEC, Serial Range: -C3751 |
| 12. | 8298072 | [1] | RING | LEC, Serial Range: -C3751 Superseded by part number: 71303857 |
| 13. | 8292220 | [1] | CYLINDER HEAD GASKET,5.34mm Thk x 149.2mm ID | LEC, Serial Range: -C3751 |
| 14. | 71446407 | [1] | SPACER | LEC, Serial Range: -C3751 |
