纽荷兰零件查询(FD80) - CRAWLER DOZER (1/98-) (3.434[01]) - HYDRAULIC SYSTEM PIPING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
292 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76591049 | [1] | HYD CONNECTOR | MAC |
| 2. | 76591034 | [2] | GASKET | MAC |
| 3. | 76591051 | [1] | HOSE | MAC |
| 4. | 76591052 | [1] | HOSE | MAC |
| 5. | 76591053 | [1] | HYD. TUBE | MAC |
| 7. | 76591054 | [1] | HOSE | MAC |
| 8. | 76591038 | [4] | HYD CONNECTOR | MAC |
| 9. | 76591029 | [2] | HYD CONNECTOR | MAC |
| 10. | 76591032 | [14] | HYD CONNECTOR | MAC |
| 11. | 76591058 | [2] | HYD. TUBE | MAC |
| 12. | 76591059 | [1] | HYD. TUBE | MAC |
| 14. | 76591061 | [2] | HOSE | MAC |
| 15. | 76593060 | [1] | HYD CONNECTOR | MAC |
| 16. | 76593061 | [1] | HOSE | MAC |
| 17. | 76591064 | [2] | SCREW | MAC |
| 18. | 76592877 | [2] | SCREW | MAC Superseded by part number: 412215 |
| 19. | 76591066 | [1] | HYDRAULIC VALVE | MAC- ASSY. SEE SGR 2.332 - TAV.4 |
| 20. | 76591067 | [1] | HYDRAULIC VALVE | MAC- ASSY. SEE SGR 2.332 - TAV.5 |
| 21. | 76591005 | [1] | HYD CONNECTOR | MAC |
| 22. | 76590847 | [4] | WASHER | MAC Superseded by part number: 10519624 |
| 23. | 76590848 | [4] | NUT | MAC- SELF-LOCKING Superseded by part number: 15503611 |
| 24. | 76593062 | [1] | HOSE | MAC |
| 25. | 76593063 | [3] | HYD CONNECTOR | MAC |
| 26. | 76591028 | [1] | HYD CONNECTOR | MAC |
| 27. | 76591073 | [1] | HYD CONNECTOR | MAC |
| 28. | 76593064 | [1] | DRAINCOCK/TAP SUPPLY | MAC |
| 30. | 76591076 | [1] | HOSE | MAC |
| 31. | 76591425 | [2] | HYDRAULIC VALVE | MAC- ASSY. SEE SGR 2.332 - TAV.2A, Serial Range: -12961065 Superseded by part number: 76595045 |
| 31. | 76595045 | [2] | HYDRAULIC VALVE | MAC- ASSY. SEE SGR 2.332 - TAV.2A 12961066, Start Serial: |
| 32. | 76591078 | [1] | HYDRAULIC VALVE | MAC- ASSY. SEE SGR 2.332 - TAV.1, Serial Range: -12961059 Superseded by part number: 76595044 |
| 32. | 76595044 | [1] | HYDRAULIC VALVE | MAC- ASSY. SEE SGR 2.332 - TAV.2A 12961060, Start Serial: |
| 33. | 76591079 | [2] | SPACER | MAC |
| 34. | 76590934 | [4] | NUT | MAC Superseded by part number: 12574221 |
| 35. | 76590873 | [4] | WASHER | MAC Superseded by part number: 10519404 |
| 36. | 76591082 | [2] | TIE-ROD | MAC |
| 37. | 76591083 | [1] | GUARD | MAC |
| 38. | 76593065 | [1] | SOLENOID VALVE | MAC- ASSY. SEE SGR 2.332 - TAV.3, Serial Range: -12961061 Superseded by part number: 76594900 |
| 38. | 76594900 | [1] | ELECTRO-VALVE | MAC- ASSY. SEE SGR 2.332 - TAV.3A 12961062, Start Serial: |
| 39. | 76592906 | [4] | PAD | MAC |
| 40. | 76591114 | [1] | CONTROL VALVE | MAC- ASSY. SEE SGR 3.436 - TAV.1 |
| 41. | 76596050 | [2] | SEAL | MAC |
| 42. | 76596047 | [18] | SEAL | MAC |
