纽荷兰零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - E70SR ASN YT04-07001 (02-008) - HYD LINES, BOOM 3.72M (EXTRA + BREAKER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
127 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT42H00081F1 | [1] | HYD LINES, BOOM 3. 72M (STD) | |
| . . | YT42H00081F2 | [1] | HYD LINES, BOOM 3. 72M (BOOM & ARM SAFETY) | |
| 1. | YT42H01253P1 | [1] | TUBE | KOB |
| 2. | YT42H01254P1 | [1] | TUBE | KOB |
| 3. | YT42H01264P1 | [1] | TUBE | KOB |
| 4. | YT42H01265P1 | [1] | TUBE | KOB |
| 5. | LF42H01009P1 | [1] | BRACKET | KOBF1 ONLY |
| 6. | 2444R402D4 | [2] | HYD CONNECTOR | HIT(Incls. O-Ring ZD12P01400) |
| 7. | ZA23F15006 | [2] | HYD CONNECTOR | KOB3/8"PF - M22x1.50 x 37mm Long (No O-Ring supplied) |
| 8. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 9. | ZE72X12000 | [2] | PLUG | KOB(3/4" PF) (Incls. O-Ring ZD12P02400) |
| 10. | ZC26X22011 | [6] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 11. | ZC36X18011 | [1] | CLAMP | KOB |
| 12. | ZC36X22011 | [3] | CLAMP | KOBDouble Line -- 75x38x13mm (Ø24mm) |
| 13. | YT42H01114P1 | [10] | CLAMP | KOB |
| 14. | YT42H01115P1 | [10] | CLAMP | KOB |
| 15. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm, F1 Only |
| 16. | ZS18C10035 | [11] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 17. | ZS18C10045 | [8] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| 18. | ZS18C10075 | [1] | SCREW,Hex, M10 x 75mm | KOBM10x1.50x75mm |
| 19. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 20. | ZW26X10000 | [22] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm, F1 Only |
| 21. | ZW16X10000 | [1] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
