沃尔沃零件查询MD120A; MD120AK; TMD120A; TMD120AK; TAMD120A; TAMD120AK; TMD120B; TAMD120B; TAMD120B-CCMiscellaneous EquipmentExtra Belt Pulley: DEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
284 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
823028
|
[1] |
Pulley, 2 grooves
|
|
| 2. |
823083
|
[1] |
Spacer ring
|
|
| 3. |
955554
|
[12] |
Hexagon screw
|
L=76mm
|
| 3. |
959804
|
[12] |
Hexagon screw
|
L=127mm
|
| 4. |
941909
|
[12] |
Spring washer
|
|
| 5. |
803689
|
[1] |
Pulley
|
|
| 6. |
915602
|
[1] |
Screw
|
|
| 7. |
804621
|
[1] |
Pulley
|
D=300mm
|
| 7. |
804664
|
[1] |
Pulley
|
D=350mm
|
| 8. |
915605
|
[1] |
Set screw
|
|
