纽荷兰零件查询(E160) - CRAWLER EXCAVATOR (N.A.) (1/06-) (09 -13[00]) - CAB - GLASS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
621 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN02C00103F4 | [1] | CAB | KOBCAB |
| 1. | YN50C00003F4 | [1] | WINDOW | KOBSee Figure 09 -15 |
| 3. | YN02C02095P1 | [2] | STOP | KOB |
| 4. | YT02C01334P1 | [2] | HOLDER | KOB |
| 5. | YT02C01081D1 | [4] | SEAL | KOB |
| 6. | YN02C02128P1 | [2] | STOP | KOB |
| 8. | YN02C02147P1 | [1] | RUBBER SLEEVE | KOB |
| 12. | YT02C01232F1 | [2] | LOCK | KOB |
| 17. | YN02C01742P1 | [2] | CATCH | KOB |
| 18. | YT02C01086P1 | [2] | GAS STRUT | KOB |
| 20. | 2420Z1227D8 | [2] | SCREW | KOB |
| 32. | YN02C01823P1 | [2] | STOP | KOB |
| 33. | YT02C01233P1 | [1] | CAP | KOB |
| 34. | 2418Z726D3 | [2] | WASHER, LOCK | KOB Superseded by part number: ZW26X06000 |
| 35. | YN02C01811P1 | [2] | PLATE | KOB |
| 36. | YN02C01656P1 | [1] | LOCK ASSY | KOB |
| 37. | YN02C01764P1 | [2] | RUBBER SLEEVE | KOB |
| 38. | YT51C01021P1 | [1] | HOOK | KOB |
| 39. | ZM66C05012 | [4] | BOLT | KOB |
| 40. | YN02C01763P1 | [2] | BRACKET | KOB |
| 41. | YT02C01261D1 | [5] | PLATE | KOB |
| 45. | YN02C01567P1 | [1] | GLASS | KOB |
| 46. | YN02C01787P1 | [1] | GLASS | KOB |
| 47. | YT02C01390P1 | [4] | WASHER,9mm ID x 20mm OD x 0.8mm Thk | KOB |
| 49. | YN02C02082P1 | [1] | GLASS | KOB |
| 50. | YN02C01794P1 | [1] | GLASS | KOB |
| 51. | YN02C01812P1 | [3] | SPACER,10mm ID x 20mm OD x 4mm L | KOB |
| 58. | YN02C02087P2 | [1] | GASKET | KOB |
| 59. | YN02C01741P1 | [1] | SEAL | KOB Superseded by part number: YN02C01741P2 |
| 63. | YR21C01161P1 | [4] | WASHER,9mm ID x 22mm OD x 2.3mm Thk | KOB |
| 65. | YN02C01821P1 | [1] | RUBBER | KOB |
| 66. | 2418Z725D3 | [5] | WASHER | KOB |
| 71. | YN02C01790P1 | [1] | HANDLE | KOB |
| 72. | ZM66C06016 | [18] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 74. | YN17M01033D3 | [3] | SCREW | KOB |
| 76. | YN02C01668P1 | [3] | RETAINER | KOB |
| 77. | YT02C01136P1 | [2] | STOP | KOB |
| 84. | ZM27C10025 | [3] | BOLT | KOB |
| 85. | YN02C01292P1 | [4] | PLUG | KOB |
| 86. | YN02C01876D1 | [8] | SCREW | KOB |
| 89. | YN02C01825P1 | [1] | SEAL,2050mm L | KOB |
| 90. | ZM46C06025 | [4] | BOLT | KOB |
| 91. | ZN18F10008 | [4] | NUT | KOB |
| 92. | ZW16X10000 | [2] | WASHER | KOB |
| 93. | YN02C02118P1 | [1] | FOAM INSULATION | KOB |
| 94. | YT02C01333P1 | [2] | WASHER | KOB |
| 95. | YN02C02119P1 | [1] | FOAM INSULATION | KOB |
| 96. | YR11M01038D1 | [8] | NUT | KOB |
| 97. | YN02C02148P1 | [1] | RUBBER | KOB |
| 98. | YN02C01652P1 | [2] | HINGE | KOB |
| 99. | YN02C01669P1 | [3] | PACKING | KOB |
| 107. | ZR36X00600 | [4] | SNAP RING | KOB |
| 109. | ZW11X10000 | [6] | WASHER | KOB Superseded by part number: ZW16X10000 |
| 110. | ZW22X10000 | [6] | LOCK WASHER | KOB Superseded by part number: ZW26X10000 |
| 111. | ZN13C10008 | [6] | NUT | KOB Superseded by part number: ZN18C10008 |
| 113. | ZS68C08025 | [2] | SCREW,Pan, M4 x 12mm | KOB |
| 114. | YT02C01229P1 | [2] | WASHER | KOB |
| 115. | YN02C01824P1 | [2] | PIN,8mm OD x 15.8mm L | KOB |
| 117. | 2420Z1227D4 | [5] | SCREW | KOB |
| 119. | 2420T4505 | [6] | WASHER,7mm ID x 16mm OD x 1mm Thk | KOB |
| 129. | YN02C02153D1 | [2] | SHIM | KOB |
| 130. | YN02C00106P1 | [1] | CAB ASSY, NOT SERVICEABLE | |
| 131. | YN51C00010F2 | [1] | DOOR ASSY. | KOBSee Figure 09 -16 |
| 132. | YN02C02002P1 | [1] | ROOF | KOB |
| 133. | YN02C02136P1 | [1] | GLASS | KOB |
| 134. | YT02C01R14D2 | [1] | SEAL | |
| 135. | YT02C01515D5 | [1] | TRIM PANEL | KOBPANEL TRIM Superseded by part number: YT02C01515D2 |
| 136. | YT02C01115D3 | [1] | RUBBER SLEEVE | KOB |
| 137. | YN02C02186P1 | [2] | SPACER | KOB |
