神钢零件查询(F4HFE613T A004) - ENGINE 504384900 - 84232924 (3/11-) (10.105.02) - SHORT BLOCK - CONNECTING ROD (5801371818 - 84364070) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
174 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2831298 | [6] | CONNECTING ROD | TORASSY |
| 1. | 2831298R | [6] | REMAN-CONNECTING ROD | TOR |
| 1. | 2831298C | [6] | CORE-ROD CONNECTING | TORReturn Number |
| 2. | 4892708 | [1] | BUSHING,38.02mm ID x 41.01mm OD x 33.4mm L | TOR |
| 3. | 2831297 | [2] | FLANGE BOLT,Hex, M10 x 1.25 x 52mm, Cl 10.9 | TOR |
| 4. | 8094961 | [6] | BEARING SET,(-0.500) | TOR |
| 4. | 8094960 | [6] | BEARING SET,(-0.250) | TOR |
| 4. | 8093882 | [6] | BEARING SET | TOR |
