| 1. |
660484R21
|
[1] |
FORK
|
IH
YOKE W/LOCK PIN Superseded by part number: 8803645
|
| 2. |
455346R21
|
[1] |
PIN
|
IH
lock Superseded by part number: 237924A1
|
| 4. |
455347R1
|
[1] |
VALVE SPRING
|
IH
SPRING, lock pin Superseded by part number: 237924A1
|
| 5. |
661406R1
|
[1] |
LOCK WASHER,4.83mm ID x 18.542mm OD x 1.65mm Thk
|
IH
X-WASHER, lock
|
| 7. |
495962R1
|
[12] |
RING
|
IH
SNAP RING
|
| 9. |
271284
|
[3] |
YOKE
|
NNA
1/8-27 65 deg Superseded by part number: 219-40, 219-40, NLS
|
| 11. |
660116R91
|
[3] |
NUT
|
IH
KIT, cross repair Superseded by part number: 84355326
|
| 12. |
666741R91
|
[1] |
YOKE
|
IH
AND SHAFT Superseded by part number: 666741R92
|
| . . |
22970R1
|
[1] |
LOCK PIN,3/8" x 2", Slotted
|
CAS
Pin, 3/8" x 2", Slotted Superseded by part number: 86624061
|
| 13. |
464920R1
|
[4] |
NYLON BEARING,2.08" ID x 2.8" OD x 0.38"
|
IH
nylon Superseded by part number: 47941, 579113
|
| 14. |
666742R91
|
[1] |
|
P
SHIELD
|
| 15. |
666743R1
|
[1] |
YOKE
|
IH
|
| 16. |
660489R1
|
[1] |
YOKE
|
IH
splined Superseded by part number: 29212
|
| 17. |
38904K
|
[1] |
SET SCREW,1/2" - 20 x 1-9/16"
|
IH
SCREW, set
|
| . . |
114496
|
[1] |
HOURMETER,Jam, 1/2"-20, G5
|
IH
NUT, 1/2-20 hex. jam Superseded by part number: 124934
|
| 18. |
666731R91
|
[1] |
GASKET
|
CAS
SHAFT, front half
|
| 19. |
674862R2
|
[1] |
YOKE
|
IH
flanged
|
| 20. |
666744R91
|
[1] |
YOKE
|
IH
AND SHAFT Superseded by part number: 666744R92
|
| 21. |
613436R1
|
[2] |
CLAMP
|
IH
SNAP RING Superseded by part number: 56760
|
| 22. |
613437R1
|
[2] |
THRUST WASHER,62.2mm ID x 71.12mm OD x 1.7mm Thk
|
IH
thrust
|
| 23. |
666745R91
|
[1] |
|
P
SHIELD, outer
|
| 24. |
666746R91
|
[1] |
RETAINER
|
IH
SHIELD, inner Superseded by part number: 666746R92
|
| 25. |
613439R1
|
[1] |
BRACKET
|
IH
BEARING, inner shield Superseded by part number: 754317
|
| 26. |
19688R1
|
[1] |
LUBE NIPPLE,1/4"-28 x .44" lg
|
IH
FITTING, 1/4 str lub Superseded by part number: 88775
|
| 27. |
666747R91
|
[1] |
TUBE ASSY.,2.125" OD, 24.625" Length
|
IH
TUBE AND SLEEVE Superseded by part number: 666747R92
|
| 28. |
674861R92
|
[1] |
|
P
SHAFT, rear half
|
| 29. |
674737R11
|
[1] |
SHIELD
|
IH
W/DECAL, power take-off brg box Superseded by part number: 674737R12
|
| . . |
88574
|
[2] |
BOLT,Hex, 5/16" - 18 x 1/2", Gr 5, Full Thd
|
NH
|
| . . |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 30. |
613174R91
|
[1] |
BALL BEARING,35 mm ID x 72 mm OD x 25 mm
|
IH
ASSY, propellar shaft front Superseded by part number: 9808112
|
| 31. |
662022R1
|
[1] |
BOX
|
IH
power take-off bearing center
|
| 32. |
674733R1
|
[1] |
SPACER
|
IH
BUSHING, power take-off pedestal
|
| . . |
189314
|
[1] |
BOLT,Hex, 1/2" - 13 x 4 3/4", Gr 5
|
IH
SCREW, 1/2-13 x 4-3/4 znd hex-hd cap Superseded by part number: 113-432, 413-876
|
| . . |
120378
|
[1] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
120384
|
[1] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| . . |
20601R1
|
[2] |
WASHER
|
IH
17/32 x 1-1/4 x 11 ga C-Z Superseded by part number: 495-81287
|
| 33. |
674734R1
|
[1] |
BRACKET
|
IH
PIVOT ASSY, bracket
|
| . . |
473873R1
|
[1] |
LOCK NUT,3/4"-16, GB
|
IH
NUT, 3/4-16 two way lock Superseded by part number: 86528769
|
| . . |
20825R1
|
[1] |
WASHER
|
IH
25/32 x 2 x 11 ga C-Z Superseded by part number: 86624158
|
| . . |
474848R1
|
[1] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2-13 znd hex. lock Superseded by part number: 231-4218
|
| 34. |
674729R1
|
[1] |
RING
|
IH
PEDESTAL ASSY, power take-off
|
| . . |
21395R1
|
[1] |
SCREW,Hex, 1/2"-13 x 5 1/4", G5
|
IH
1/2-13 x 5-1/4 znd hex-hd cap Superseded by part number: 280290
|
| 35. |
UA20551
|
[1] |
RING
|
IH
propellar shaft bearing snap
|
| 36. |
674732R1
|
[2] |
SPACER
|
IH
BUSHING, power take-off pedestal
|
| 37. |
87569
|
[2] |
LUBE NIPPLE,45 Degree, 1/4" NPT x 4/5" L, Drive
|
PA
FITTING, 1/4-28 45 deg self tap lub
|
