| 2. |
455347R1
|
[1] |
VALVE SPRING
|
IH
SPRING, lock pin Superseded by part number: 237924A1
|
| 3. |
661406R1
|
[1] |
LOCK WASHER,4.83mm ID x 18.542mm OD x 1.65mm Thk
|
IH
X-WASHER, lock
|
| 4. |
455346R21
|
[1] |
PIN
|
IH
lock Superseded by part number: 237924A1
|
| 6. |
668335R11
|
[1] |
FORK
|
IH
YOKE W/LOCK PIN Superseded by part number: 568100R93
|
| 7. |
80711
|
[2] |
LUBE NIPPLE,65 Degree, 1/8" NPT x 7/8" lg
|
NH
FITTING, 1/8 65 deg lub
|
| 8. |
667498R1
|
[8] |
RING
|
IH
SNAP RING, cross brg retainer
|
| 9. |
667497R91
|
[8] |
BEARING ASSY
|
IH
cross
|
| 11. |
667496R91
|
[2] |
SPIDER ASSY.
|
IH
KIT, cross repair Superseded by part number: 84355319
|
| 12. |
668334R91
|
[1] |
|
P
YOKE AND SHAFT, tractor half
|
| 13. |
613436R1
|
[2] |
CLAMP
|
IH
RING, snap Superseded by part number: 56760
|
| 14. |
464920R1
|
[2] |
NYLON BEARING,2.08" ID x 2.8" OD x 0.38"
|
IH
nylon Superseded by part number: 47941, 579113
|
| 15. |
668333R1
|
[1] |
SHIELD
|
IH
outer
|
| 16. |
668338R1
|
[1] |
SHIELD
|
IH
inner
|
| 17. |
613439R1
|
[1] |
BRACKET
|
IH
BEARING, center nylon Superseded by part number: 754317
|
| 18. |
19688R1
|
[1] |
LUBE NIPPLE,1/4"-28 x .44" lg
|
IH
FITTING, 1/4 str lub Superseded by part number: 88775
|
| 19. |
668339R91
|
[1] |
|
P
YOKE AND TUBE, implement half 22.62" Length
|
| 20. |
663101R92
|
[1] |
YOKE
|
IH
implement
|
| 21. |
668331R91
|
[1] |
SHAFT
|
IH
tractor half, chain belt
|
| 22. |
668332R91
|
[1] |
|
P
SHAFT, implement half, chain belt
|
| 25. |
569044R91
|
[8] |
BEARING ASSY
|
IH
needle Superseded by part number: 84355319
|
| 26. |
576420R1
|
[8] |
RING
|
IH
bearing retainer snap
|
| 28. |
200464C91
|
[2] |
PACKAGE
|
IH
KIT, cross repair Superseded by part number: 84355319
|
| 29. |
667817R91
|
[1] |
YOKE
|
IH
AND TUBE
|
| 32. |
613437R1
|
[4] |
THRUST WASHER,62.2mm ID x 71.12mm OD x 1.7mm Thk
|
IH
thrust
|
| 35. |
668404R91
|
[1] |
SHIELD
|
IH
inner
|
| 36. |
668405R91
|
[1] |
SHIELD
|
IH
outer
|
| 37. |
667816R91
|
[1] |
YOKE
|
IH
AND SHAFT, rectangular
|
| 43. |
568100R92
|
[1] |
YOKE
|
IH
W/QUICK ATTACHING PIN Superseded by part number: 568100R93
|
| 44. |
668370R91
|
[1] |
JOINT
|
IH
SHAFT, tractor half, Rockwell, standard Superseded by part number: 668370R92
|
| 45. |
668371R92
|
[1] |
JOINT
|
IH
SHAFT, mach half, Rockwell, standard
|
| 46. |
87569
|
[4] |
LUBE NIPPLE,45 Degree, 1/4" NPT x 4/5" L, Drive
|
PA
FITTING, 1/4-28 45 deg self tap lub
|
| 1. |
674380R2
|
[1] |
STABILIZER
|
IH
wire container
|
| . . |
17452R1
|
[3] |
BOLT,Hex, 1/2"-13 x 1 1/4", G2
|
IH
1/2 x 1-1/4 znd hex-hd mach Superseded by part number: 180175
|
| . . |
120378
|
[3] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
120384
|
[3] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| . . |
178373R1
|
[2] |
WASHER
|
IH
17/32 x 1 x 16 ga C-Z Superseded by part number: 495-51053
|
| 2. |
667845R93
|
[1] |
CONTAINER
|
IH
ASSY, four coil wire
|
| 3. |
11883PB
|
[1] |
GUIDE, wire
|
|
| 4. |
11792P
|
[1] |
HOLDER
|
IH
BRACKET, wire guide
|
| . . |
18654R1
|
[2] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 2
|
IH
1/4 x 3/4 znd hex-hd mach Superseded by part number: 424-412
|
| . . |
120375
|
[2] |
NUT,Hex, 1/4" - 20, Gr 5
|
IH
Superseded by part number: 7770
|
| . . |
492-11025
|
[2] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| 1. |
671104R1
|
[1] |
|
P
RETAINER, pressure plate
|
| . . |
436732
|
[2] |
SCREW,Slotted Pan Hd, #10-24 x 1/2"
|
IH
10-24 x 1/2 C-Z slt-pan-hd mach Superseded by part number: 70-1108
|
| . . |
120361
|
[2] |
NUT,Hex Mach Screw, #10 - 24
|
IH
Superseded by part number: 87304
|
| . . |
120217
|
[2] |
LOCK WASHER,#10
|
IH
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 2. |
671103R1
|
[1] |
|
P
PLATE, pressure
|
| 3. |
366317R93
|
[1] |
SWITCH
|
IH
|
| 3. |
366317R93GV
|
[1] |
CONTROL
|
MKT
Value, Control Switch
|
| 4. |
671102R1
|
[1] |
|
P
PLATE, switch mounting
|
| 5. |
671101R1
|
[1] |
|
P
SUPPORT, switch mounting plate
|
| . . |
18474R1
|
[2] |
BOLT,Hex, 5/16" - 18 x 1", Gr 2
|
IH
5/16 x 1 C-Z hex-hd mach Superseded by part number: 424-516
|
| . . |
120376
|
[2] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 6. |
664547R91
|
[2] |
|
P
WIRE, lead
|
| 7. |
140568
|
[3] |
CLAMP
|
IH
CLIP, 5/16 x 9/16 no. 5 closed
|
