纽荷兰零件查询(E200SR) - CRAWLER EXCAVATOR BTW YB04-02319 - YB04-02550 (01-043[03]) - GUARD INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
190 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB21C00005F2 | [1] | GUARD INSTAL | |
| 1. | YB21C01038F1 | [1] | BODY | KOBBOX ASSY |
| 1-1. | YB21C01061P1 | [1] | BOXED PANEL | KOB |
| 1-2F. | YX21C01056P1 | [2] | HINGE | KOB |
| 1-2G. | YN21C01258P1 | [1] | LOCK | KOB |
| 1-3. | YN21C01552P1 | [1] | STAY | KOBSTAY |
| 1-4. | HY25X10027G1 | [2] | WASHER,10mm ID x 27mm OD x 3.2mm Thk | KOB |
| 1-5. | 2419R9D2 | [2] | COTTER PIN | KOBSNAP |
| 1-6. | ZM32C12025 | [2] | BOLT | KOBSEMS |
| 1-8. | YN21C01710D4 | [1] | RUBBER WEATHERSTRIP | KOB |
| 1-9. | YN21C01704P1 | [1] | INSULATING PANEL | KOB |
| 1-10. | PY06C01040P1 | [1] | STOP | KOB |
| 1-11. | ZN18F10008 | [1] | NUT | KOB |
| 2. | YN21C01706F1 | [1] | PANEL | KOBASSY |
| 2-1. | YN21C01616P2 | [1] | PANEL | KOB |
| 2-2. | YN21C01705P1 | [1] | FOAM INSULATION | KOB |
| 3. | YN21C01691F1 | [1] | PANEL | KOBASSY |
| 3-1. | YN21C01613P4 | [1] | COWLING | KOBPANEL |
| 3-1H. | YN21C01707P1 | [2] | HINGE | KOB |
| 3-2. | PH21C01021D8 | [1] | RUBBER WEATHERSTRIP | KOB |
| 3-3. | YX21C01204P1 | [1] | STAY | KOBSTAY |
| 3-4. | YR21C01123P1 | [1] | COLLAR | KOB |
| 7. | YN21C01749P2 | [1] | COVER | KOB |
| 8. | YN21C01686F4 | [1] | COVER | KOBASSY |
| 8-3. | YF21C01051P1 | [1] | FOAM INSULATION | KOB |
| 8-4. | YN21C01815P1 | [1] | COVER | KOB |
| 8-5. | YN21C01692D4 | [1] | SOFT TRIM | KOB Superseded by part number: YN21C01692D8 |
| 8-6. | YB21C01074P1 | [1] | FOAM INSULATION | KOB |
| 11. | YB21C01039F1 | [1] | COVER | KOBASSY |
| 11-1. | YB21C01068P1 | [1] | GUARD | KOB |
| 11-2. | YT21C01034P2 | [1] | CATCH | KOB |
| 11-3. | ZM61C06016 | [2] | BOLT | KOBSEMS |
| 11-4. | YN21C01438F2 | [1] | LOCK | KOBASSY |
| 11-4A. | YR22C01025P2 | [1] | LOCK | KOB |
| 11-4C. | YN21C01702P1 | [1] | PLATE | KOB |
| 11-5. | YT21C01143P1 | [2] | RUBBER SLEEVE | KOB |
| 11-6. | YN21C01572P1 | [1] | ROD | KOB |
| 11-7. | YT21C01053P1 | [2] | CLIP | KOB |
| 11-8. | YW21C01057D4 | [1] | WEATHERSEAL STRIP | KOBSTRIP, WEATHER |
| 11-9. | YN21C01181P1 | [1] | HANDLE | KOB |
| 11-10. | ZM12C08020 | [2] | BOLT | KOBSEMS |
| 11-11. | ZW16X08000 | [2] | WASHER | KOB |
| 11-12. | PY01P01019D9 | [1] | WEATHERSEAL STRIP | KOBSTRIP, WEATHER |
| 12. | YB21C01040F1 | [1] | COVER | KOBASSY |
| 12-1. | YB21C01063P1 | [1] | GUARD | KOB |
| 12-2. | YJ21C01146D3 | [1] | INSULATING PANEL | KOB |
| 12-3. | YJ21C01079D2 | [1] | WEATHERSTRIP | KOB |
| 14. | YB21C01042F1 | [1] | GUARD | KOBASSY |
| 14-1. | YB21C01022P1 | [1] | COVER | KOB |
| 14-2. | YW21C01057D9 | [1] | WEATHERSTRIP | KOB |
| 14-3. | YT21C01163DE | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| 14-4. | YN21C01136D4 | [1] | WEATHERSTRIP | KOB |
| 14-5. | YN21C01687P1 | [1] | GRIP | KOB |
| 14-6. | YB21C01072P1 | [1] | FOAM INSULATION | KOB |
| 15. | YB21C01043F1 | [1] | COVER | KOBASSY |
| 15-1. | YB21C01004P1 | [1] | GUARD | KOB |
| 15-2. | YB21C01033P1 | [1] | INSULATING PANEL | KOB |
| 16. | YB21C01087P1 | [1] | GUARD | KOB |
| 17. | YB21C01044F2 | [1] | U-BRACKET | KOBASSY |
| 17-2. | YB21C01034D1 | [1] | INSULATING PANEL | KOB |
| 17-3. | YN21C01530P1 | [1] | INSULATING PANEL | KOB |
| 17-4. | YB21C01035D1 | [1] | LABEL | KOB |
| 17-5. | YB21C01080P1 | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| 17-6. | YB21C01081P1 | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| 17-7. | YT21C01163D1 | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| 17-8. | LE21C01070DK | [1] | WEATHERSEAL STRIP | KOBSTRIP, WEATHER |
| 17-9. | PY01P01019D1 | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| 17-10. | YB21C01092P2 | [1] | U-BRACKET | KOB |
| 18. | YB21C01139F1 | [1] | GUARD | KOBASSY |
| 18-1. | YB21C01142P1 | [1] | GUARD | KOB |
| 18-4. | YN21C01722P1 | [1] | GUARD | KOB |
| 18-7. | LE21C01070DQ | [1] | WEATHERSEAL STRIP | KOBSTRIP, WEATHER |
| 18-8. | YB21C01036D2 | [1] | RUBBER | KOB |
| 19. | YB21C01062P1 | [1] | U-BRACKET | KOB |
| 20. | YB21C01079F1 | [1] | GUARD | KOBASSY |
| 20-1. | YB21C01077P1 | [1] | GUARD | KOB |
| 20-2. | YB21C01078P1 | [1] | INSULATING PANEL | KOB |
| 21. | YN21C01751F1 | [1] | BRACKET | KOBASSY |
| 21-1. | YN21C01743P1 | [1] | BRACKET | KOB |
| 22. | YN21C01440P1 | [1] | HINGE | KOB |
| 23. | YN21C01434P2 | [1] | STAY | KOBSTAY |
| 24. | YB21C01021P1 | [1] | SUPPORT | KOB |
| 25. | YB21C01047F1 | [1] | GUARD | KOBASSY |
| 25-1. | YB21C01023P1 | [1] | GUARD | KOB |
| 25-2. | 2427P1836D14 | [1] | WEATHERSTRIP | KOB |
| 25-3. | PH03M01281P1 | [1] | GROMMET | KOB |
| 26. | YW21C01302P1 | [1] | GAS STRUT | KOBSPRING, GAS |
| 31. | YN21C01321P1 | [4] | STOP | KOB Superseded by part number: YN21C03212P1 |
| 33. | YN21C01748P1 | [1] | STRIKER PLATE | KOB |
| 36. | ZM32C12030 | [60] | BOLT | KOBSEMS |
| 37. | HS18C10025G1 | [3] | SCREW | KOBCAP Superseded by part number: ZS18C10025 |
| 38. | HY25X11024G1 | [3] | WASHER | KOB |
| 39. | YT21C01172P1 | [3] | LOCK WASHER | KOB |
| 41. | YW21C01180P1 | [2] | GAS STRUT | KOBGAS |
| 42. | YN21C01467P2 | [1] | STRIKER PLATE | KOB |
| 43. | YN21C01174D1 | [1] | SPACER | KOB |
| 44. | YN21C01174D2 | [1] | SPACER | KOB |
| 45. | YB21C01050F1 | [1] | U-BRACKET | KOBASSY |
| 45-1. | YB21C01007P2 | [1] | U-BRACKET | KOB |
| 45-2. | YB21C01071D1 | [1] | INSULATING PANEL | KOB |
| 47. | YB21C01051F2 | [1] | GUARD | KOBASSY |
| 47-2. | YN21C01528D6 | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| 47-3. | YJ21C01080D5 | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| 47-4. | YJ21C01080D6 | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| 47-6. | LE21C01070D2 | [1] | RUBBER WEATHERSTRIP | KOBSTRIP, WEATHER |
| 47-8. | YB21C01084P1 | [1] | GUARD | KOB |
| 47-9. | 2416Z440D7 | [1] | INSULATING PANEL | KOB |
| 47-10. | YR21C01251D1 | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| 49. | YB21C01088P2 | [1] | STAY | KOBSTAY |
| 51. | ZS18C12035 | [4] | SCREW,Hex, M12 x 35mm | KOBCAP |
| 52. | YB21C01064P1 | [1] | COVER | KOB |
| 53. | YB21C01025P1 | [1] | GUARD | KOB |
| 54. | YB21C01024P1 | [1] | GUARD | KOB |
| 55. | YB21C01030P1 | [1] | STRIKER PLATE | KOB |
| 56. | YN21C01752P1 | [4] | BOLT | KOB |
| 57. | YT21C01179D1 | [1] | SHIM | KOB(1.2) |
| 58. | YX21C01165D2 | [2] | SPACER | KOB |
| 59. | HY35X13025G1 | [1] | WASHER | KOB |
| 61. | ZS18C12045 | [6] | SCREW,Hex, M12 x 45mm | KOBCAP |
| 62. | ZS18C12070 | [2] | SCREW,Hex, M12 x 70mm | KOBCAP |
| 63. | YN21C01694P1 | [1] | STRIKER PLATE | KOB |
| 64. | ZS18C12025 | [5] | SCREW,Hex, M12 x 25mm | KOBCAP |
| 65. | YN21C01685P1 | [1] | STAY | KOBSTAY |
| 67. | YT21C01187P2 | [2] | WASHER | KOB |
| 68. | YB21C01006P1 | [1] | GUARD | KOB |
| 70. | ZN18C12010 | [2] | NUT | KOB |
| 71. | 2418T10357 | [21] | WASHER | KOB Superseded by part number: 2418T12345 |
| 72. | ZW26X12000 | [24] | WASHER | KOB |
| 73. | YN21C01175D1 | [1] | SHIM | KOB(1.6) |
| 74. | YN21C01175D2 | [1] | SHIM | KOB(2.3) |
| 77. | YN21C01713P1 | [1] | U-BRACKET | KOB |
| 78. | ZS18C12065 | [4] | SCREW,Hex, M12 x 65mm | KOBCAP |
| 79. | 2418T17912D1 | [3] | WASHER | KOB |
| 80. | ZS18C12030 | [1] | SCREW,Hex, M12 x 30mm | KOBCAP |
| 81. | YB21C01020P1 | [1] | HINGE | KOB |
| 82. | YB21C01067P1 | [1] | U-BRACKET | KOB |
| 83. | YB21C01052F1 | [1] | COVER | KOBASSY |
| 83-1. | YB21C01055P1 | [1] | COVER | KOB |
| 83-2. | YB21C01073D1 | [1] | GASKET | KOB |
| 84. | YB21C01152P1 | [1] | GUARD | KOB |
| 85. | YB21C01153P1 | [1] | GUARD | KOB |
| 86. | YB21C01057P1 | [1] | U-BRACKET | KOB |
| 87. | YB21C01082P1 | [1] | PLATE | KOB |
| 89. | YB21C01140F1 | [1] | GUARD | KOBASSY |
| 89-1. | YB21C01141P1 | [1] | COVER | KOB |
| 89-2. | YN21C01712D9 | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| 89-3. | PH03M01264D4 | [1] | INSULATING PANEL | KOBRUBBER Superseded by part number: PH03M01264D3 |
| 89-6. | PH03M01264D7 | [1] | INSULATING PANEL | KOB Superseded by part number: PH03M01264D3 |
| 89-7. | PH03M01264D2 | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| 91. | YN21C01535F4 | [1] | GUARD | KOBASSY |
| 91-1. | YN21C01754P2 | [1] | COVER | KOB |
| 91-1D. | YN21C01725P2 | [2] | HINGE | KOB |
| 91-2A. | YR22C01025P1 | [1] | LOCK | KOB Superseded by part number: YR22C01025P2 |
| 91-4. | YN21C01756P1 | [1] | ROD | KOB |
| 91-6. | ZM11C06014 | [2] | SCREW | KOBSEMS-BOLT |
| 91-7. | ZW16X06000 | [2] | WASHER | KOB Superseded by part number: 86588450 |
| 91-10. | YN21C01567P1 | [1] | STRIKER PLATE | KOB |
| 91-14. | YN21C01734P2 | [1] | STAY | KOBSTAY |
| 91-19. | YN21C01757D1 | [1] | SHIM | KOB(1.2) |
| 91-20. | YN21C01757D2 | [1] | SHIM | KOB(2.0) |
| 91-21. | YN21C01757D3 | [1] | SHIM | KOB(3.2) |
| 91-24. | 2420Z1341 | [1] | GROMMET | KOB |
| 91-26. | YX14E01004P1 | [2] | GROMMET | KOB |
| 91-28. | YF21C01001P1 | [1] | GUARD | KOB |
| 91-29. | PM22C01020DH | [1] | INSULATING PANEL | KOB |
| 92. | YB22C00002F2 | [1] | GUARD | KOBASSY |
| 92-2. | YT21C01163DC | [1] | WEATHERSTRIP | KOB |
| 92-3. | YJ21C01079DD | [1] | RUBBER WEATHERSTRIP | KOB |
| 92-4. | YT21C01163D3 | [1] | WEATHERSTRIP | KOB |
| 92-5. | YB22C01005P1 | [1] | FOAM INSULATION | KOB |
| 92-6. | YB22C01006P1 | [1] | FOAM INSULATION | KOB |
| 92-7. | YB22C01039P1 | [1] | GUARD | KOBBONNET |
| 93-2. | YA21C01036D4 | [1] | WEATHERSEAL STRIP | KOB |
| 93-4. | YT21C01163DB | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| 93-5. | YW21C01057D7 | [1] | RUBBER WEATHERSTRIP | KOB |
| 93-6. | LE21C01070DG | [1] | RUBBER WEATHERSTRIP | KOB |
| 93-7. | 2427P1836D10 | [1] | WEATHERSTRIP | KOB |
| 93-8. | YT21C01163DA | [1] | WEATHERSEAL STRIP | KOBSTRIP, WEATHER |
| 93-10. | YB22C01003P1 | [1] | FOAM INSULATION | KOB, Serial Range: LA04-01506-LA04-01545 Superseded by part number: YB22C01003P2 |
| 93-10. | YB22C01003P2 | [1] | INSULATION | KOBINSULATION, Start Serial: LA04-01546 |
| 93-13. | YB22C01009P1 | [1] | FOAM INSULATION | KOB |
| 93-14. | YB22C01010P1 | [1] | FOAM INSULATION | KOB |
| 93-15. | YB22C01011P1 | [1] | FOAM INSULATION | KOB |
| 93-17. | YB22C01013P1 | [1] | FOAM INSULATION | KOB |
| 93-18. | YB22C01038P1 | [1] | GUARD | KOBBONNET |
| 93-19. | YB22C01041P1 | [1] | INSULATING PANEL | KOB |
| 94. | YB21C01156F1 | [1] | GUARD | KOBASSY |
| 94-1. | YB21C01154P1 | [1] | GUARD | KOB |
| 94-2. | YB21C01032P1 | [1] | INSULATING PANEL | KOB |
| 94-3. | YJ21C01103D4 | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| 94-4. | YT21C01159D6 | [1] | WEATHERSTRIP | KOB |
| 94-5. | YT21C01297DA | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
