201676C91
|
[2] |
TWISTER
|
IH
ASSY
|
| 1. |
657188R3
|
[1] |
KNIFE
|
IH
wire
|
| . . |
18475R1
|
[2] |
BOLT,Hex, 5/16" - 18 x 1 1/4", Gr 2
|
IH
5/16 x 1-1/4 znd hex-hd mach Superseded by part number: 424-520
|
| . . |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 2. |
657164R1
|
[8] |
SHIM
|
IH
wire knife and keeper blade .010
|
| 2. |
203188C1
|
[2] |
SHIM
|
IH
wire .003, (or as required)
|
| 2. |
203189C1
|
[1] |
SHIM
|
IH
wire .007, (or as required)
|
| 3. |
657128R1
|
[1] |
SPACER
|
IH
wire knife
|
| 4. |
657126R2
|
[1] |
HOLDER
|
IH
DISC, wire holder lower
|
| . . |
133846
|
[4] |
SCREW,Sl Flat Hd, 5/16" - 18 x 1 1/2"
|
IH
|
| 5. |
657127R3
|
[1] |
BLADE
|
IH
wire holder keeper
|
| . . |
18764R1
|
[1] |
HARDWARE,Hex, 5/16"-18 x 3/4", G2
|
IH
BOLT, 5/16 x 3/4 znd hex-hd mach Superseded by part number: 424-512
|
| 6. |
657124R2
|
[1] |
SPACER
|
IH
wire holder disc
|
| 7. |
201679C1
|
[1] |
DISC
|
IH
wire holder upper
|
| 8. |
656893R1
|
[1] |
HUB
|
IH
wire holder disk
|
| . . |
21832R1
|
[1] |
LOCK PIN,1/4" x 2", Slotted
|
IH
Pin, 1/4" x 2", Slotted Superseded by part number: 87020818
|
| 9. |
87415
|
[3] |
LUBE NIPPLE,90 Degree, 1/4" NPT x 3/4" L, Drive
|
NH
NIPPLE, LUBE, 90°, 1/4" NPT x .75" lg, Drive
|
| 10. |
87569
|
[1] |
LUBE NIPPLE,45 Degree, 1/4" NPT x 4/5" L, Drive
|
PA
FITTING, 1/4-28, 45 deg angle self-tap. lubrication
|
| 11. |
657163R1
|
[3] |
SHIM
|
IH
keeper blade .010
|
| 12. |
656948R1
|
[1] |
SHAFT
|
IH
wire holder
|
| . . |
178373R1
|
[1] |
WASHER
|
IH
17/32 x 1 x 16 ga C-Z Superseded by part number: 495-51053
|
| . . |
120371
|
[1] |
NUT,1/2"-20, G5
|
IH
Superseded by part number: 280963
|
| . . |
25-158
|
[1] |
JAM NUT,Jam, 1/2"-20, G5
|
CAS
1/2-20 znd hex. jam Superseded by part number: 425-158
|
| . . |
178375R1
|
[1] |
WASHER
|
IH
25/32 x 1-1/4 x 16 ga C-Z, (or as required) Superseded by part number: 249100
|
| . . |
21757R1
|
[1] |
WASHER
|
IH
25/32 x 1-1/4 x 22 ga C-Z, (or as required) Superseded by part number: 87613196
|
| 13. |
656947R1
|
[1] |
BLOCK DRIVER
|
IH
PINION, wire clamp and cutter helical driver
|
| 14. |
658967R1
|
[7] |
SHIM
|
IH
disk pinion adjusting, (or as required)
|
| 15. |
201680C1
|
[1] |
GEAR
|
IH
PINION, twister hook
|
| . . |
21830R1
|
[1] |
LOCK PIN,3/16" x 1 1/4", Slotted
|
IH
Pin, 3/16" x 1 1/4", Slotted Superseded by part number: 87020816
|
| 16. |
201681C91
|
[1] |
HOOK
|
IH
ASSY, wire twister
|
| . . |
19336R1
|
[1] |
LOCK PIN,1/8" x 11/16", Slotted
|
IH
Pin, 1/8" x 11/16", Slotted Superseded by part number: 38-1811
|
| . . |
18810R1
|
[4] |
BOLT,Hex, 1/2" - 13 x 2 1/4", Gr 2
|
IH
1/2 x 2-1/4 znd hex-hd mach. Superseded by part number: 113-441
|
| . . |
120378
|
[1] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
120384
|
[1] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| . . |
607895R1
|
[1] |
WASHER
|
IH
17/32 x 1 x 11 ga C-Z Superseded by part number: 86624146
|
| 17. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, 1/4-28 str self-tap. lub
|
| . . |
113-233
|
[2] |
BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5
|
CAS
3/8-16 x 1-3/4 znd hex-hd cap Superseded by part number: 9706689
|
| . . |
366862C1
|
[1] |
LOCK WASHER,3/8"
|
IH
3/8" Superseded by part number: 80680
|
| 19. |
657001R1
|
[1] |
BUSHING
|
IH
wire holder shaft
|
| 20. |
656912R2
|
[1] |
DISC
|
IH
PINION, disk
|
| . . |
22981R1
|
[1] |
ROLL PIN,1/4" x 2 1/4", Slotted
|
IH
Pin, 1/4" x 2 1/4", Slotted Superseded by part number: 657197R1
|
| . . |
22920R1
|
[2] |
LOCK PIN,5/32" x 1", Slotted
|
IH
PIN, 5/32" x 1", Slotted Superseded by part number: 86624058
|
| 21. |
201678C1
|
[1] |
SHAFT
|
IH
disk pinion
|
| . . |
21758R1
|
[1] |
WASHER
|
IH
25/32 x 1-1/4 x 14 ga C-Z, (or as required) Superseded by part number: 495-81038
|
| 22. |
656946R1
|
[1] |
PINION
|
IH
wire clamp and cutter helical drive
|
| . . |
21648R1
|
[1] |
LOCK PIN,1/4" x 1 1/4", Slotted
|
IH
Pin, 1/4" x 1 1/4", Slotted Superseded by part number: 438-11620
|
| . . |
23277R1
|
[1] |
LOCK PIN,5/32" x 1 1/4", Slotted
|
IH
PIN, 5/32" x 1 1/4", Slotted Superseded by part number: 17080R1
|
