| 1. |
667841R1
|
[1] |
|
P
BEARING, twister shaft left, 430 Baler 50 in thru 001193, 440 Baler 50 in thru 001303
|
| 1. |
674347R1
|
[1] |
FLANGE
|
IH
BEARING, twister shaft left, 430 Baler 001194 and up, 440 Baler 001304 and up
|
| . . |
18495R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 2
|
IH
3/8 x 1-1/4 znd hex-hd mach Superseded by part number: 180124
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
366862C1
|
[2] |
LOCK WASHER,3/8"
|
IH
3/8" Superseded by part number: 80680
|
| 2. |
664773R1
|
[1] |
SHAFT
|
IH
wire twister
|
| . . |
608085R1
|
[1] |
WASHER
|
IH
1-13/32 x 2 x 16 ga C-Z Superseded by part number: 495-81213
|
| . . |
68676H
|
[14] |
WASHER
|
IH
1-13/32 x 1-3/4 x 22 ga, (or as required)
|
| . . |
432-1232
|
[1] |
COTTER PIN,3/16" OD x 2" L
|
CAS
3/16" x 2" Superseded by part number: 87400
|
| 3. |
657783R91
|
[2] |
TWISTER
|
IH
HOOK ASSY, wire twister
|
| . . |
23280R1
|
[2] |
PIN, 1/8 x 11/16 C-Z slt spring
|
|
| . . |
18497R1
|
[2] |
BOLT,Hex, 1/2"-13 x 1 3/4", G2
|
IH
1/2 x 1-3/4 znd hex-hd mach Superseded by part number: 179887
|
| . . |
120384
|
[2] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| . . |
607895R1
|
[2] |
WASHER
|
IH
17/32 x 1 x 11 ga C-Z Superseded by part number: 86624146
|
| 4. |
656913R2
|
[2] |
PINION
|
IH
twister
|
| . . |
21832R1
|
[2] |
LOCK PIN,1/4" x 2", Slotted
|
IH
Pin, 1/4" x 2", Slotted Superseded by part number: 87020818
|
| 5. |
656895R22
|
[1] |
TWISTER
|
IH
ASSY, LH
|
| 5. |
656895R2
|
[1] |
TWISTER
|
IH
FRAME, wire twister LH Superseded by part number: 656895R22
|
| 6. |
657163R1
|
[6] |
SHIM
|
IH
keeper blade .010
|
| 7. |
656947R1
|
[2] |
BLOCK DRIVER
|
IH
PINION, wire clamp & cutter helical
|
| 8. |
657128R1
|
[2] |
SPACER
|
IH
wire knife
|
| 9. |
657164R1
|
[16] |
SHIM
|
IH
wire knife & keeper blade
|
| 10. |
656948R1
|
[2] |
SHAFT
|
IH
wire holder
|
| . . |
Q5035
|
[2] |
WASHER
|
IH
17/32 x 1 x 16 ga. Superseded by part number: 495-81254
|
| . . |
551658R1
|
[8] |
WASHER
|
IH
25/32 x 1-1/4 x 22 ga., (or as req.) Superseded by part number: 87613196
|
| . . |
25-118
|
[2] |
NUT,1/2"-20, G5
|
CAS
1/2 NF Superseded by part number: 425-118
|
| . . |
114496
|
[2] |
HOURMETER,Jam, 1/2"-20, G5
|
IH
NUT, jam 1/2 NF Superseded by part number: 124934
|
| 11. |
656893R1
|
[2] |
HUB
|
IH
wire holder disc
|
| 12. |
657123R2
|
[2] |
HOLDER
|
IH
DISC, wire holder
|
| 13. |
657124R2
|
[2] |
SPACER
|
IH
wire holder disc
|
| 14. |
657127R2
|
[2] |
NO LONGER SERVICED
|
IH
BLADE, wire holder keeper Superseded by part number: 657127R3
|
| . . |
17411R1
|
[2] |
BOLT,Hex, 5/16"-18 X 3/4", G2
|
IH
mach. 5/16 x 3/4 Superseded by part number: 179816
|
| . . |
103320
|
[2] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 15. |
657126R2
|
[2] |
HOLDER
|
IH
DISC, wire holder lower
|
| . . |
113918
|
[8] |
FENDER
|
NNA
fl. hd. sl. 5/16 x 1-1/2 Superseded by part number: NLS
|
| 16. |
657188R3
|
[2] |
KNIFE
|
IH
wire
|
| . . |
17445R1
|
[4] |
BOLT,Hex, 5/16" - 18 x 1 1/4"
|
IH
mach. 5/16 x 1-1/4 Superseded by part number: 87657
|
| 17. |
80717
|
[1] |
LUBE NIPPLE,45 Degree, 1/8" NPT x 7/8" lg
|
NH
FITTING, 1/8 45 deg lub
|
| 18. |
332040
|
[6] |
LUBE NIPPLE,90 Degree, 1/8" NPT x .84" lg
|
WIN
FITTING, 1/8 90 deg lub
|
| 19. |
667438R1
|
[2] |
SHIM
|
IH
wire twister shaft, .020
|
| 19. |
667439R1
|
[14] |
SHIM
|
IH
wire twister shaft, .005, (or as required)
|
| 20. |
656890R2
|
[1] |
CAM
|
IH
GEAR & STRIPPER CAM HOLDER, twister
|
| . . |
181705
|
[1] |
|
NNA
SCREW, 1/2-20 x 2 znd hex-hd cap Superseded by part number: 114-410
|
| 21. |
658967R1
|
[2] |
SHIM
|
IH
disk pinion adj.
|
| 22. |
656946R1
|
[2] |
PINION
|
IH
wire clamp & cutter helical
|
| . . |
21648R1
|
[2] |
LOCK PIN,1/4" x 1 1/4", Slotted
|
IH
Pin, 1/4" x 1 1/4", Slotted Superseded by part number: 438-11620
|
| . . |
23277R1
|
[2] |
LOCK PIN,5/32" x 1 1/4", Slotted
|
IH
PIN, 5/32" x 1 1/4", Slotted Superseded by part number: 17080R1
|
| 23. |
656949R1
|
[2] |
GEAR
|
IH
SHAFT, disk pinion
|
| . . |
Q3478
|
[8] |
WASHER
|
IH
25/32 x 1-1/4 x 14 ga. Superseded by part number: 495-81038
|
| . . |
Q3501
|
[8] |
WASHER
|
IH
25/32 x 1-1/4 x 16 ga. Superseded by part number: 95-81056
|
| 24. |
656912R2
|
[2] |
DISC
|
IH
PINION, disk
|
| . . |
22981R1
|
[2] |
ROLL PIN,1/4" x 2 1/4", Slotted
|
IH
Pin, 1/4" x 2 1/4", Slotted Superseded by part number: 657197R1
|
| . . |
22920R1
|
[4] |
LOCK PIN,5/32" x 1", Slotted
|
IH
PIN, 5/32" x 1", Slotted Superseded by part number: 86624058
|
| 25. |
656894R12
|
[1] |
TWISTER
|
IH
ASM R.H.
|
| 25. |
656894R1
|
[1] |
TWISTER
|
IH
FRAME, wire twister R.H.
|
| 26. |
664760R1
|
[1] |
CAM
|
IH
GEAR, trip dog carrier & wire twister
|
| . . |
86837295
|
[1] |
SCREW, 1/2 x 2 znd hex-hd cap
|
GUIDE
|
| 27. |
663378R1
|
[1] |
PAWL
|
IH
DOG, auxiliary trip
|
| 28. |
664947R1
|
[1] |
PIVOT
|
IH
trip dog
|
| . . |
21755R1
|
[1] |
WASHER
|
IH
15/32 x 13/16 x 18 ga C-Z, (or as required)
|
| . . |
21756R1
|
[1] |
WASHER
|
IH
15/32 x 3/4 x 22 ga, (or as required) Superseded by part number: 86624145
|
| 29. |
R1003
|
[1] |
SPRING
|
IH
auxiliary trip dog
|
| 31. |
V341
|
[1] |
PAWL
|
IH
ROLLER, trip dog
|
| 32. |
663478R11
|
[1] |
PAWL
|
IH
DOG & ROLLER, trip
|
| 33. |
V690
|
[1] |
PIN
|
IH
STUD, trip dog roller
|
| 34. |
V680
|
[1] |
SPRING
|
IH
trip dog Superseded by part number: 753027R1
|
| 36. |
669630R91
|
[1] |
SUPPORT
|
IH
W/BUSHING, twister and gear insert
|
| . . |
179885
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5
|
IH
Superseded by part number: 87689
|
| . . |
103323
|
[2] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| 38. |
674353R11
|
[1] |
GEAR
|
IH
W/BUSHING, twister drive
|
| 39. |
667826R1
|
[1] |
BUSHING
|
IH
knotter drive gear
|
| 40. |
667844R1
|
[1] |
BUSHING
|
IH
twister shaft
|
| 41. |
361017R91
|
[1] |
BALL BEARING,1.9685" ID x 3.5433 mm OD x 0.7894 mm
|
IH
twister drive gear, replaces 271255R91 Superseded by part number: 87591960
|
| 42. |
287049R1
|
[1] |
SNAP RING,#196, Ext
|
IH
Ring, Snap, , twister drive gear bearing #196, Ext Superseded by part number: 9671310
|
| 43. |
16964R91
|
[1] |
FITTING
|
IH
1/4 90 deg lub Superseded by part number: 87414
|
| 44. |
109461
|
[8] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 45. |
657001R1
|
[2] |
BUSHING
|
IH
wire holder shaft
|
| 46. |
658735R2
|
[1] |
|
P
PIVOT & SUPPORT STRIPPER ACTUATING ARM
|
| . . |
17446R1
|
[2] |
BOLT,3/8" - 16 x 1 1/4", Gr 2
|
IH
mach. 3/8 x 1-1/4 Superseded by part number: 88011
|
| . . |
18780R1
|
[1] |
BOLT,Hex, 3/8"-16 x 1 3/4", G2
|
IH
3/8 x 1-3/4 znd hex-hd mach Superseded by part number: 424-628
|
| . . |
120382
|
[3] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 47. |
11309N
|
[2] |
SPACER
|
IH
twister cover, regular for 440 Baler, special for 430 Baler
|
| . . |
19570R1
|
[2] |
BOLT,Hex, 1/4" - 20 x 5/8", Gr 2
|
IH
1/4-20 x 5/8 cd-pltd hex-hd mach Superseded by part number: 280641
|
| . . |
492-11025
|
[2] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| . . |
120392
|
[2] |
WASHER,1/4", SAE
|
IH
9/32 x 5/8 x 16 ga C-Z Superseded by part number: 87361
|
| 48. |
667784R92
|
[1] |
COVER
|
IH
twister, regular for 440 Baler, special for 430 Baler
|
| 49. |
658737R91
|
[1] |
ARM
|
IH
stripper actuating cpt.
|
| . . |
22765R1
|
[2] |
WASHER
|
IH
21/32 x 1-1/2 x 22 ga C-Z Superseded by part number: 86625246
|
| . . |
648002
|
[1] |
1/8" x 3/4"
|
KNIFE
|
| 50. |
656952R1
|
[1] |
ROLLER
|
IH
stripper arm
|
| 51. |
658740R1
|
[1] |
SUPPORT
|
IH
ADJUSTMENT STRIPPER ACTUATING ARM
|
| . . |
19020R1
|
[2] |
PLOW BOLT,#3, 3/8" - 16 x 1 1/4", Gr 2
|
IH
BOLT, 3/8 x 1-1/4 znd No. 3 plow Superseded by part number: 19031R1
|
| . . |
469668R1
|
[2] |
WASHER
|
IH
13/32 x 3/4 x 16 ga C-Z Superseded by part number: 86632580
|
| 52. |
667787R1
|
[1] |
SPRING
|
IH
twister cover, regular for 440 Baler, special for 430 Baler
|
| . . |
110638
|
[2] |
RIVET
|
IH
button hd. 3/16 x 5/16
|
| 53. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, lub. 1/4-28 str self tapping
|
| 54. |
657206R1
|
[1] |
KEY,3/8" Sq x 2 3/8", Par
|
CAS
sq. 3/8 x 2-3/8
|
| 55. |
Q72
|
[1] |
KEY,5/16" Sq x 1 7/8", Par
|
IH
sq. 3/8 x 1-7/8
|
| 56. |
674104R1
|
[1] |
GEAR
|
IH
PINION, auger drive idler
|
| 57. |
674464R91
|
[1] |
BEARING ASSY,0.6267" ID x 1.1811" OD x 1.531"
|
IH
ASSY, auger drive
|
| . . |
23685R1
|
[1] |
SET SCREW,Hex Soc, 3/8"-16 x 1 3/4"
|
IH
Cup Pt Hex Soc, 3/8"-16 x 1 3/4" Superseded by part number: 483-13828
|
| . . |
124829
|
[1] |
JAM NUT,Hex, 3/8" - 16, Gr 5
|
IH
Superseded by part number: 329-146
|
