纽荷兰零件查询(E200SR) - CRAWLER EXCAVATOR BTW YB04-02319 - YB04-02550 (01-051) - CONDITIONER ASSY, AIR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
138 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB20M00004F1 | [1] | CONDITIONER ASSY, AIR | |
| 1. | YX20M01022P1 | [1] | BRACKET | KOB |
| 2. | YB20M01009P1 | [1] | SUPPORT | KOB |
| 3. | YB20M01010P1 | [1] | SUPPORT | KOB |
| 4. | R18T0026D29 | [2] | HOSE,12mm ID x 4150mm L | KOB |
| 5. | 2418T23147 | [2] | SPACER | KOB |
| 6. | YN20M01046DL | [2] | RIGID TUBE,22.10mm ID x 27.00mm OD x 3800.00mm | KOB |
| 7. | YN20M01094DC | [1] | RIGID TUBE,25mm ID x 30mm OD x 2800mm Length | KOB |
| 8. | 2418Z1333D23 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1900mm Length | KOB |
| 9. | 2418Z1333D21 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 3200mm Length | KOB |
| 10. | ZC16X02000 | [4] | CLIP | KOB |
| 11. | PY01P01043D5 | [4] | CABLE TIE,301mm L | KOB |
| 12. | 2432R325 | [2] | CLIP | KOB |
| 14. | ZS18C08016 | [2] | SCREW,Hex, M8 x 16mm | KOBCAP |
| 15. | ZS18C08100 | [4] | SCREW,Hex, M8 x 100mm | KOBSCREW |
| 16. | ZS18C06050 | [6] | SCREW,Hex, M6 x 50mm | KOBCAP |
| 17. | ZS18C06020 | [2] | SCREW,Hex, M6 x 20mm | KOBCAP |
| 18. | ZS18F10050 | [2] | BOLT,Hex, M10 x 50mm | KOBCAPSCREW |
| 19. | ZS18F10060 | [2] | SCREW | KOBCAP |
| 20. | ZW16X06000 | [8] | WASHER | KOB Superseded by part number: 86588450 |
| 21. | ZW16X08000 | [6] | WASHER | KOB |
| 23. | ZW26X06000 | [6] | LOCK WASHER | KOB |
| 24. | ZW26X08000 | [4] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| 25. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| 26. | YT20M01043P1 | [1] | GROMMET | KOB |
| 27. | YX20M01025P1 | [1] | V-BELT,42.92" L | KOB(COG B42) Superseded by part number: 84214719 |
| 28. | ZW16H10000 | [6] | WASHER | KOB |
| 29. | 2432R233D1 | [1] | CLIP | KOB |
