| 1. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
FITTING, 1/4-28 NS 3/4 str lub Superseded by part number: 87414
|
| 4. |
667970R91
|
[1] |
|
P
STRAP ASSY, fuel tank, 2 for units A, B, C and D
|
| . . |
17351R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 C-Z sq-nk crg Superseded by part number: 88682
|
| . . |
18784R1
|
[2] |
BOLT,Hex, 3/8"-16 x 2 3/4", G2
|
IH
3/8 x 2-3/4 C-z hex-hd mach Superseded by part number: 88444
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
120394
|
[4] |
WASHER,3/8", SAE
|
IH
WASHER, 13/32 x 13/16 x 16 ga C-Z Superseded by part number: 87016
|
| 5. |
668110R1
|
[1] |
|
P
RETAINER, belt, unit E
|
| . . |
180121
|
[3] |
BOLT,Hex, 3/8" - 16 x 7/8", Gr 5
|
IH
SCREW, 3/8 x 7/8 C-Z hex-hd cap Superseded by part number: 280643
|
| . . |
477589R1
|
[3] |
WASHER
|
IH
13/32 x 1-1/2 x 11 ga C-Z Superseded by part number: 86637594
|
| 6. |
589951R1
|
[1] |
PLUG
|
IH
CAP, hub pulley
|
| 7. |
661249R1
|
[1] |
|
P
WHEEL, crank, units A, B, C and D
|
| 8. |
651815R91
|
[1] |
BEARING ASSY,7.508" ID x 17.82" OD x 6"
|
IH
BEARING ASSY, idler pulley outer cone Superseded by part number: 179080
|
| 8. |
651815R91GV
|
[1] |
BEARING CONE
|
MKT
Value, Cone Bearing
|
| . . |
608701R1
|
[2] |
WASHER
|
IH
21/32 x 1-1/4, 16 ga C-Z Superseded by part number: 86624155
|
| . . |
125267
|
[1] |
NUT
|
IH
5/8-18 C-Z slt hex. Superseded by part number: 425-1310, 425-1310, NLS
|
| . . |
137185
|
[1] |
COTTER PIN,1/8" x 1"
|
IH
PIN, SPLIT (COTTER), 1/8" x 1" Superseded by part number: 80755
|
| 9. |
651814R1
|
[1] |
BEARING CUP
|
IH
BEARING, idler pulley outer cup Superseded by part number: 36725
|
| 10. |
564407R1
|
[1] |
|
P
PULLEY, engine idler
|
| 11. |
662339R1
|
[1] |
BELT,3.50" W x 97.75" L
|
IH
Engine drive, Units A, B, C and D 3.50" W x 97.75" L
|
| 11. |
668111R1
|
[1] |
BELT,3.50" W
|
IH
Drive, Unit E 3.50" W
|
| 12. |
662053R11
|
[1] |
|
P
PULLEY W/SET SCREWS, engine
|
| . . |
668806R1
|
[2] |
|
P
SCREW, 3/8-16 x 3/4 hex. soc-hd cup pt nylock set
|
| 13. |
564405R1
|
[1] |
RING, SNAP
|
IH
RING, idler pulley snap
|
| 14. |
651817R1
|
[1] |
BEARING CUP
|
IH
BEARING, idler pulley inner cup Superseded by part number: 84356153
|
| 15. |
668946R91
|
[1] |
|
P
BRACKET ASSY, engine idler
|
| . . |
23183R1
|
[1] |
WASHER
|
IH
29/32 x 1-3/8 x 16 ga C-Z, (or as required) Superseded by part number: 495-81054
|
| . . |
21762R1
|
[3] |
WASHER
|
IH
29/32 x 1-3/8 x 10 ga C-Z Superseded by part number: 495-81055
|
| . . |
137204
|
[1] |
COTTER PIN,1/8" x 1 1/2"
|
IH
PIN, SPLIT (COTTER), 1/8" x 1 1/2" Superseded by part number: 80708
|
| 16. |
667942R1
|
[2] |
|
P
BUSHING, engine idler support
|
| . . |
180153
|
[4] |
BOLT,Hex, 7/16" - 14 x 2", Gr 5
|
IH
SCREW, 7/16-14 x 2 C-Z hex-hd cap Superseded by part number: 326-732
|
| . . |
473213R1
|
[4] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 C-Z hex. lock Superseded by part number: 280980
|
| . . |
120383
|
[4] |
LOCK WASHER,Helical Spring, 7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| . . |
21760R1
|
[2] |
WASHER,0.47" ID x 0.88" OD x 0.19" Thk
|
IH
15/32 x 7/8 x 7 ga C-Z
|
| . . |
607891R1
|
[2] |
WASHER
|
IH
15/32 x 1 x 16 ga znp Superseded by part number: 495-81158
|
| 17. |
663935R21
|
[1] |
|
P
SUPPORT W/BUSHINGS, engine
|
| 18. |
222-762
|
[1] |
ELBOW,90 Degree, 7/16"-20, 45 Degree Fl x 1/8" NPT
|
CAS
tube, for fuel line, units A, B, C and D 90º, 7/16"-20, 45º Fl x 1/8" NPT
|
| 19. |
86534426
|
[1] |
ELBOW
|
CAS
street 1/8, for fuel line, units A, B, C and D Superseded by part number: CAS86534426, CAS86534426, NNA86534426
|
| 20. |
668105R1
|
[1] |
|
P
ADAPTER, engine base RH, unit E
|
| . . |
17452R1
|
[2] |
BOLT,Hex, 1/2"-13 x 1 1/4", G2
|
IH
1/2-13 x 1-1/4 znp hex-hd mach Superseded by part number: 180175
|
| . . |
120384
|
[2] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| 21. |
668034R2
|
[1] |
|
P
ANGLE, bale chamber reinforcement
|
| . . |
18778R1
|
[1] |
SCREW,Hex, 3/8"-16 x 3/4", G2
|
IH
BOLT, 3/8 x 3/4 C-Z hex-hd mach, 4 for units A and D, 2 for units B, C and E Superseded by part number: 180120
|
| . . |
469668R1
|
[2] |
WASHER
|
IH
13/32 x 3/4 x 16 ga znp Superseded by part number: 86632580
|
| 22. |
668104R1
|
[1] |
|
P
ADAPTER, engine base LH, unit E
|
| . . |
271723
|
[1] |
SNAP RING,Hex, 5/8" - 11 x 2", Gr 5
|
NNA
SCREW, 5/8-11 x 2 C-Z hex-hd cap Superseded by part number: 413-1032, 413-1032, NLS
|
| . . |
492-11062
|
[1] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 23. |
662338R1
|
[2] |
SPACER
|
IH
engine base
|
| 24. |
12989R1
|
[1] |
|
P
NIPPLE, 3/8 x 1-1/2, for oil drain Nipple, 3/8" NPT x 7 1/2"
|
| 25. |
110675
|
[1] |
CAP,3/8" NPT
|
CAS
pipe Superseded by part number: 221-1524
|
| 26. |
659495R1
|
[1] |
|
P
STOP, engine idler lever
|
| . . |
18494R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
3/8 x 1 C-Z hex-hd mach Superseded by part number: 424-616
|
| 27. |
662340R1
|
[1] |
GRIP
|
IH
lever, replaces 66930R1
|
| 28. |
27385D
|
[1] |
|
P
CLIP, loom for 3/8 bolt, for fuel line, units A, B, C and D
|
| 29. |
52728D
|
[2] |
|
P
CUSHION, fuel line felt
|
| 30. |
27386D
|
[1] |
|
P
CLIP, loom for 1/2 bolt, for fuel line
|
| 31. |
667968R1
|
[1] |
|
P
SPACER, fuel tank
|
| 32. |
668410R1
|
[1] |
|
P
SUPPORT, fuel tank, unit E
|
| 33. |
668690R91
|
[1] |
|
P
TANK W/CAP, fuel, unit E
|
| 36. |
668112R91
|
[2] |
|
P
STRAP ASSY, fuel tank, unit E
|
| 37. |
667969R1
|
[1] |
|
P
SUPPORT, fuel tank, units A, B, C and D
|
| 38. |
651818R91
|
[1] |
ROLLER BEARING,31.77 mm ID x 16.08 mm
|
IH
BEARING ASSY, idler pulley inner cone Superseded by part number: 84356153
|
| 39. |
564403R91
|
[1] |
SEAL
|
IH
engine idler pulley oil Superseded by part number: 46876
|
| 40. |
657205R1
|
[1] |
|
P
KEY, 3/8 x 3-1/4 sq parallel 3/8" Sq x 3 1/4", Par
|
| . . |
1001721R1
|
[1] |
|
P
DECAL, arrow, on crank wheel, units A, B, C & D
|
