凯斯零件查询(440) - INTERNATIONAL HARVESTER RECTANGULAR BALER (NORTH AMERICA) (1/70-12/78) (E-70) - WISCONSIN ENGINE ATTACHMENT ELECTRICAL SYSTEM, 12 VOLT, WHEN ORDERED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
717 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
614129R11
|
[1] |
|
P
COVER ASSY, battery
|
| 2. |
PO22778
|
[1] |
SPACER,1/4" Pipe x 2"
|
IH
Hold down bolt 1/4" Pipe x 2"
|
| 3. |
614132R1
|
[1] |
|
P
BOLT, battery box-long
|
| . . |
665621R1
|
[1] |
|
P
NUT, 1/4-20 wing
|
| 4. |
56277D
|
[1] |
|
P
CLIP, cable
|
| 5. |
614131R1
|
[1] |
|
P
BOLT, battery box-short
|
| . . |
86627130
|
[1] |
WING NUT,1/4"-20
|
NH
NUT, 1/4-20 znd wing
|
| 6. |
672143R91
|
[1] |
|
P
CABLE, Serial Range: battery-starter
|
| 7. |
672144R91
|
[1] |
|
P
CABLE ASSY, Serial Range: battery-ground
|
| . . |
18778R1
|
[1] |
SCREW,Hex, 3/8"-16 x 3/4", G2
|
IH
BOLT, 3/8 x 3/4 C-Z hex-hd mach Superseded by part number: 180120
|
| . . |
120377
|
[1] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[1] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 9. |
674481R1
|
[1] |
|
P
SUPPORT, battery tray
|
| . . |
18494R1
|
[3] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
3/8 x 1 C-Z hex-hd mach Superseded by part number: 424-616
|
| . . |
469668R1
|
[2] |
WASHER
|
IH
13/32 x 3/4 x 16 ga znp Superseded by part number: 86632580
|
| 10. |
614126R92
|
[1] |
|
P
TRAY ASSY, battery
|
| . . |
16897R1
|
[4] |
CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 5/16 x 3/4 C-Z sq-nk crg Superseded by part number: 412-512
|
| . . |
120376
|
[4] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
80681
|
[4] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
