| 1. |
674380R2
|
[1] |
STABILIZER
|
IH
wire container
|
| . . |
17452R1
|
[3] |
BOLT,Hex, 1/2"-13 x 1 1/4", G2
|
IH
1/2 x 1-1/4 C-Z hex-hd mach Superseded by part number: 180175
|
| . . |
120378
|
[3] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
120384
|
[3] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| . . |
178373R1
|
[2] |
WASHER
|
IH
17/32 x 1 x 16 ga C-Z Superseded by part number: 495-51053
|
| 2. |
11792P
|
[1] |
HOLDER
|
IH
BRACKET, wire guide
|
| . . |
18654R1
|
[2] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 2
|
IH
1/4 x 3/4 znd hex-hd mach Superseded by part number: 424-412
|
| . . |
120375
|
[2] |
NUT,Hex, 1/4" - 20, Gr 5
|
IH
Superseded by part number: 7770
|
| . . |
492-11025
|
[2] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| 3. |
11833PB
|
[1] |
GUIDE
|
IH
wire Superseded by part number: 1344948C1
|
| 4. |
667874R92
|
[1] |
NO LONGER SERVICED
|
IH
CONTAINER ASSY, two coil wire Superseded by part number: 667874R93
|
| . . |
17140R1
|
[2] |
CARRIAGE BOLT,Short Nk, 1/2" - 13 x 1 1/4", Gr 2, Full Thd
|
IH
BOLT, 1/2 x 1-1/4 C-Z sq-nk crg Superseded by part number: 87868
|
| 5. |
667819R1
|
[2] |
CAM
|
IH
STRAP, retainer, 430W Balers 001503 and below, 440W Balers 002028 and below Superseded by part number: 667819R2
|
| . . |
22750R1
|
[4] |
PIN
|
IH
1/4 x 5/8 znp std-hd Superseded by part number: 22906R1
|
| . . |
119117
|
[4] |
COTTER PIN,3/32" x 1/2"
|
IH
PIN - COTTER, 3/32 x 1/2 znp
|
| . . |
20600R1
|
[2] |
WASHER
|
IH
9/32 x 3/4 x 11 ga C-Z Superseded by part number: 86624138
|
| 6. |
667858R1
|
[2] |
ROD
|
IH
retainer, 430W Balers 001503 and below, 440W Balers 002028 and below
|
| . . |
121222
|
[2] |
COTTER PIN,3/32" x 3/4"
|
IH
PIN, SPLIT (COTTER), 3/32" x 3/4" Superseded by part number: 132-321
|
| . . |
120393
|
[2] |
BEARING WASHER,5/16", SAE
|
IH
WASHER, 11/32 x 11/16 x .065 ga C-Z Superseded by part number: 28588R1
|
| . . |
7500032
|
[2] |
BUSHING
|
NUT, 5/16-18 C-Z wing
|
