纽荷兰零件查询(E200SR) - CRAWLER EXCAVATOR BTW YB04-02319 - YB04-02550 (01-055) - DRIER ASSY, AIR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
331 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB96V00001F2 | [1] | HEATER | KOBDRIER ASSY, AIR |
| 1. | YT54S00002P1 | [1] | RECEIVER-DRIER | KOB |
| 3. | YN20M01240F1 | [1] | HOSE | KOBASSY |
| 3-2. | 2445Z1604D6 | [2] | O-RING | KOB |
| 4. | YB20M01003F1 | [1] | HOSE | KOBASSY |
| 4-2. | 2445Z1604D4 | [2] | O-RING | KOB |
| 5. | YB20M01004F1 | [1] | HOSE | KOBASSY |
| 5-2. | 2445Z1604D5 | [2] | O-RING | KOB |
| 6. | YB20M01005F1 | [1] | HOSE | KOBASSY |
| 7. | YX20M01030F1 | [1] | RIGID TUBE | KOBASSY |
| 8. | YX20M01034F1 | [1] | ELBOW | KOBASSY |
| 9. | YT96V00001S009 | [2] | SCREW | KOBSCREW |
| 10. | YT20M00009S005 | [4] | BOLT | KOBCAP |
| 11. | YN20M01355P1 | [1] | BRACKET | KOB |
