纽荷兰零件查询(E200SR) - CRAWLER EXCAVATOR BTW YB04-02319 - YB04-02550 (01-064[02]) - HARNESS ASSY, ENGINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
682 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB16E00001F2 | [1] | HARNESS ASSY, ENGINE, Start Serial: LA04-01550 | |
| 1. | YB16E01001P1 | [1] | HARNESS | KOB, Serial Range: LA04-01506-LA04-01549 |
| 2. | YX16E01004P1 | [1] | U-BRACKET | KOB |
| 3. | ZS18C10014 | [1] | SCREW,Hex, M10 x 14mm | KOBCAP |
| 4. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 5. | ZW16X10000 | [2] | WASHER | KOB |
| 6. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 7. | PY01P01043D3 | [4] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long, Serial Range: LA04-01506-LA04-01549 |
| 8. | 2432R233D3 | [2] | CLIP | KOB |
| 9. | ZW16X06000 | [1] | WASHER | KOB Superseded by part number: 86588450 |
| 10. | ZS18C05012 | [1] | SCREW,Hex, M5 x 12mm | KOBCAP |
| 11. | ZW26X05000 | [1] | LOCK WASHER | KOBLOCK |
