纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (03-002) - HYD LINES, BOOM 5.05M New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
940 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 02. | YB01V00009F2 | [1] | HYDRAULIC CYLINDER | KOBASSY, BOOM (LH) |
| 03. | YB01V00010F2 | [1] | HYDRAULIC CYLINDER | KOBASSY, ARM |
| . . | YB42H00007F1 | [1] | HYD LINES,BOOM | |
| A1. | YB42H01049P1 | [1] | TUBE | KOB |
| A2. | YB42H01040P1 | [1] | ELBOW | KOB |
| A3. | YB42H01041P1 | [1] | TUBE | KOB |
| A4. | YB42H01050P1 | [1] | TUBE | KOB |
| A5. | ZX20H12140 | [1] | FLEXIBLE HOSE | KOB |
| A6. | ZX20H12145 | [2] | FLEXIBLE HOSE | KOB |
| A7. | ZD12A01800 | [7] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| A8. | 2432T2434 | [2] | CLAMP | KOB |
| A9. | ZC36X28014 | [2] | CLAMP | KOB |
| A10. | ZC26X28014 | [4] | CLAMP | KOB |
| A11. | ZS18C12055 | [6] | SCREW,Hex, M12 x 55mm | KOBCAP |
| A12. | ZW26X12000 | [8] | WASHER | KOB |
| A13. | YX03H01046P1 | [4] | CLIP | KOB |
| A14. | ZD12A02100 | [1] | O-RING | KOB |
| A15. | YB42H01088D1 | [1] | FLEXIBLE HOSE | KOB |
| A16. | ZS18C12060 | [2] | SCREW,Hex, M12 x 60mm | KOBCAP |
| A17. | 2414Z199D75 | [1] | GUARD | KOB |
| A18. | 2414Z199D100 | [1] | GUARD | KOB |
| . . | YB42H00019F1 | [1] | HYD LINES, CYLINDER | |
| B1. | YB42H01015P1 | [1] | TUBE | KOBTUBE |
| B2. | YB42H01053P1 | [1] | TUBE | KOBTUBE |
| B3. | YB42H01066P1 | [1] | RIGID TUBE | KOB |
| B4. | YB42H01067P1 | [1] | RIGID TUBE | KOB |
| B5. | ZX20H12086 | [2] | FLEXIBLE HOSE | KOB |
| B6. | ZX20H10086 | [2] | FLEXIBLE HOSE | KOB |
| B7. | 2432T2242 | [2] | CLAMP | KOB |
| B8. | ZS18C12050 | [2] | SCREW,Hex, M12 x 50mm | KOBCAP |
| B9. | ZS28C10030 | [16] | SCREW,Hex Socket Head, M10 x 30mm | KOBCAP |
| B10. | ZH22Z04000 | [2] | HYD CONNECTOR | KOB |
| B11. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOBGREASE |
| B13. | ZD12A01600 | [2] | O-RING | KOB |
| B14. | ZD12P02600 | [4] | O-RING | KOB |
| B16. | ZE72X04000 | [1] | PLUG | KOB |
| . . | YB42H00021F1 | [1] | HYD LINES, CYLINDER | |
| C1. | YM42H01031P1 | [1] | TUBE,1474, 196 mm L | KOB |
| C3. | ZX30U12086 | [1] | FLEXIBLE HOSE | KOB |
| C4. | YN43H01097P1 | [1] | CLAMP | KOB |
| C6. | ZE13X12000 | [2] | CLAMP | KOBHALF |
| C8. | ZS28C10035 | [8] | SCREW,Hex Socket Head, M10 x 35mm | KOBSCREW |
| C12. | ZW26K10000 | [4] | LOCK WASHER | KOBLOCK |
