纽荷兰零件查询(E200SRLC) - CRAWLER EXCAVATOR BTW LA04-01506 - LA04-01625 (03-006) - ARM ASSY, STD 2.6M New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
885 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB12B00045F1 | [1] | ARM GROUP | |
| A1. | YB12B01009F1 | [1] | LINK | KOBASSY BUCKET |
| A1-1. | NSS | [1] | NOT SERVICED SEPARATELY | CONLINK, BUCKET |
| A1-2. | YN12B01230P1 | [2] | BUSHING | KOB |
| A1-3. | YN12B01083P1 | [2] | BUSHING | KOB |
| A2. | YB12B01007P1 | [1] | LINK | KOB |
| A3. | YB12B01008P1 | [1] | LINK | KOB |
| A4. | YB12B01046P1 | [2] | PIN | KOB Superseded by part number: YN12B01073P1 |
| A5. | YN12B01307P1 | [1] | PIN | KOB |
| A6. | LQ12B01089P1 | [1] | PIN | KOB |
| A7. | HS18C16130G2 | [1] | BOLT,Hex, M16 x 130mm, Cl 10.9 | KOBCAP |
| A8. | HS18C16140G2 | [1] | SCREW,M16 x 140mm, Cl 10.9 | KOBCAP |
| A9. | ZN18C16013 | [4] | NUT | KOB |
| A10. | 2445R220D4 | [8] | SEAL,78.7mm ID x 95mm OD x 5mm Thk | KOBDUST |
| A11. | 2445R220D3 | [2] | SEAL,70mm ID x 85mm OD x 5mm Thk | KOBDUST |
| A12. | 2445R138D7 | [2] | SEAL,80mm ID x 95mm OD x 4mm Thk | KOBDUST |
| A13. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOBGREASE |
| A14. | ZG91U02000 | [1] | LUBE NIPPLE | KOBGREASE |
| A15. | B16T0442D57 | [1] | SHIM,0.5mm Thk | KOB |
| A16. | B16T0442D44 | [1] | SHIM,0.9mm Thk | KOB |
| A17. | B16T0442D1 | [1] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOB(1.2) |
| A18. | B16T0442D2 | [1] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOB(1.6) |
| A19. | YN12B01122D1 | [2] | SHIM,82mm ID x 140mm OD x 0.5mm Thk | KOB(0.5) |
| A20. | YN12B01122D2 | [2] | SHIM,82mm ID x 140mm OD x 0.9mm Thk | KOB(0.9) |
| A21. | YN12B01122D3 | [2] | SHIM,82mm ID x 140mm OD x 1.6mm Thk | KOB(1.6) |
| . . | YB12B00013F1 | [1] | ARM | KOBARM ASSY |
| B1-2. | 2418T25783 | [1] | PLATE | KOBPLATE |
| B2. | 2405T1888 | [2] | BUSHING | KOB |
| B3. | YN12B01213P1 | [2] | BUSHING | KOB |
| B4. | YN12B01079P1 | [2] | BUSHING | KOB |
| . . | YM12B00005F2 | [1] | ARM INSTAL | |
| C1. | YM12B01008P1 | [1] | PIN | KOB |
| C3. | 2418T12645D2 | [1] | PLATE | KOB |
| C5. | ZS18C12025 | [2] | SCREW,Hex, M12 x 25mm | KOBCAP |
| C7. | B16T0442D52 | [2] | SHIM,82mm ID x 100mm OD x 0.5mm Thk | KOB(0.5) |
| C8. | B16T0442D39 | [2] | SHIM,82mm ID x 150mm OD x 0.9mm Thk | KOB(0.9) |
| C9. | B16T0442D3 | [1] | SHIM,150mm OD x 82mm ID x 1.2mm Thk | KOB(1.2) |
| C10. | B16T0442D4 | [1] | SHIM,0.9mm Thk | KOB(1.6) |
| C11. | YM12B01014P2 | [1] | PIN | KOB Superseded by part number: YB12B01073P1 |
| C18. | ZW16H12000 | [2] | WASHER | KOB |
